Figure 41
SET ESAM: PHONE PARAMETERS: XUT PARAMETERS: COMPANDING screen
Enter Compander Type
1 - uLaw, 2 - aLaw, <cr> - No Change
Slot 0 Existing Compander Type - uLaw New Type - 2 Type Now - aLaw
XUT Setup Menu for XUT
1 - Companding
2 - 10PPS1 Make/Break Ratio
3 - 10PPS2 Make/Break Ratio
4 - 20PPS Make/Break Ratio
9 - Return To Main Menu
Figure 42
SET ESAM: PHONE PARAMETERS: XUT PARAMETERS: 10PPSI MAKE/BREAK RATIO
screen
Enter 10PPS1 Make/Break Ratio [Current Value - 1] - 2
XUT Setup Menu for XUT
1 - Companding
2 - 10PPS1 Make/Break Ratio
3 - 10PPS2 Make/Break Ratio
4 - 20PPS Make/Break Ratio
9 - Return To Main Menu
b 10PPS1 Make/Break Ratio - This variation of the SET
ESAM:XUT PARAMETERS command allows the user to change
the 10PPS1 Make/Break Ratio from its default of 0. Its display is
similar to Figure 42.
c 10PPS2 Make/Break Ratio - This variation of the SET
ESAM:XUT PARAMETERS command allows the user to change
the 10PPS2 Make/Break Ratio from its default of 0. Its display is
similar to Figure 43.
