Nortel Meridian 1 Mini-Carrier Remote Description, Installation, And Maintenance page 52

Page 52 of 150 Installation and configuration
Table 5
Mini-Carrier Remote-unique hardware list
Component
LMI (IPE)
NT5D64
LMX (IPE)
NT5D65
RMI
NT5D67
LMI (Option 11)
NT5D68
LMX (Option 11)
NT5D69
LMI Multi-I/O
Cable Assembly
NT5D85
LMI/LMX Multi-I\O
Cable Assembly
NT5D86
P0914209 Standard 3.00 April 2000
Local Mini-Carrier Interface card (LMI) for installation in IPE shelf line card
slots.
Local Mini-Carrier Extender card (LMX) for installation in IPE shelf line card
slots. Up to three LMXs may be installed, depending on configuration.
Remote Mini-Carrier Interface card (RMI) for installation in remote site Option
11 cabinets.
Local Mini-Carrier Interface card (LMI) for installation in Option 11 cabinet line
card slots.
Local Mini-Carrier Extender card (LMX) for installation in Option 11 cabinet
line card slots. Up to three LMXs may be installed, depending on configuration.
This 2 ft. cable has a 50-pin Amphenol connector at one end that fits the
connector for the first of the two line card slots occupied by the LMI.
The opposite end has five connectors
connectors are for:
P2 First T1 carrier link
P3 Second T1 carrier link
P4 External alarm
P5 Man-Machine Interface (MMI)
P6 Serial Data Interface (SDI)
This 2 ft. cable has a
connector for the second of the two line card slots occupied by the LMI. The
opposite end has three connectors, which are for:
P2 LMX1
P3 LMX 2
P4 LMX3
Description
, see Figure 5 on page 17.
50-pin Amphenol
connector at one end that fits the I/O
(See Figure 6 on page 18.)
—continued—
I\O
The five
