RMI Multi-I/O cable assembly
Figure 7
RMI Multi-I/O Cable Assembly (NT5D87)
Carrier 0 Carrier 1
P2
RMI Multi-I/O cable assembly (NT5D87) provides the remote site interface
between the RMI and the MMI, Alarm, and the T1 carrier links. See "RMI
Multi-I/O cable assembly" on page 131 for pin-out information.
P3
P1 of the
remote
Option 11
cabinet
Mini-Carrier Remote Description, Installation, and Maintenance
Alarm
MMI
P4
P5
P1
RMI
Description
Page 19 of 150
Not Used
P6
