RMI Multi-I/O cable assembly

W3 BLK
W3 RED
W3 BLK
W3 GRN
W3 BLK
W3 BLU
Table 25 associates the connectors on the RMI Multi-I/O cable assembly
(NT5D87) to its correct connection:
Table 25
RMI Multi-I/O cable assembly (NT5D87) connections
CONN CONNECTS TO
P1 RMI
P2 T1 Link 0
P3 T1 Link 1
P4 alarm
P5 man-machine interface (MMI)
P6 not used
Table 26 on page 132 is the pin-out table for the RMI Multi-I/O cable
assembly (NT5D87):
Mini-Carrier Remote Description, Installation, and Maintenance
Appendix C: Pin-outs
—continued—
P1 - 18 P5 - 9
P1 - 43 P5 - 34
P1 - 19 P5 - 12
P1 - 44 P6 - 37
P1 - 20 P6 - 11
P1 - 45 P6 - 36
—end—
Page 131 of 150
DS30XMXRX2+
DS30XMXRX2-
COMTXD2+
COMTXD2-
COMRXD2+
COMRXD2-
