Page 94 of 150 Installation and configuration
Figure 43
SET ESAM: PHONE PARAMETERS: XUT PARAMETERS: 10PPS2 MAKE/BREAK RATIO
screen
Enter 10PPS2 Make/Break Ratio [Current Value - 1] - 2
XUT Setup Menu for XUT
1 - Companding
2 - 10PPS1 Make/Break Ratio
3 - 10PPS2 Make/Break Ratio
4 - 20PPS Make/Break Ratio
9 - Return To Main Menu
Figure 44
SET ESAM: PHONE PARAMETERS: XUT PARAMETERS: 20PPS MAKE/BREAK RATIO
screen
Enter 20PPS Make/Break Ratio [Current Value - 1] - 2
XUT Setup Menu for XUT
1 - Companding
2 - 10PPS1 Make/Break Ratio
3 - 10PPS2 Make/Break Ratio
4 - 20PPS Make/Break Ratio
9 - Return To Main Menu
P0914209 Standard 3.00 April 2000
d 20PPS Make/Break Ratio - This variation of the SET ESAM:XUT
PARAMETERS command allows the user to change the 20PPS
Make/Break Ratio from its default of 0. Its display is similar to
Figure 44.
6 Trunk Parameters - This variation of the SET ESAM command
allows the user to change the parameters of any of the 8 trunks on the
current board. Its display is similar to Figure 45.
