Page 78 of 150 Installation and configuration
MMI Login
MMI Password
Basic MMI Commands
P0914209 Standard 3.00 April 2000
Each MCR must be configured individually, even if the MCR resides in a
daisy-chain configuration. To configure the MMI firmware for MCR, you
must login to that particular MCR. Passwords must be upper case. All other
commands are not case-sensitive.
• For single MCR installations, log in by typing L or LOGIN.
• For MCRs in a daisy-chain configuration, log-in by typing L <XX> or
LOGIN <XX>, where XX is the two-digit decimal address of the MCR
set by the DIP switches. The command LOGIN and the address must be
separated by a space. For example, to log-in to a MCR with an address
of 31, you would enter the command L 31 or LOGIN 31. All MCR
addresses must be two digits. For example, a MCR with an address of 1,
should be entered as 01.
After logging in, you will be prompted to enter a password. The password is
MCRLINK. The MMI command line prompt in the initial mode is MCR>,
but, after entering the password correctly, the prompt will look as follows:
• MCR::> for single MCR installations
• MCRXX> for MCRs installed in a daisy chain xx represents the two-digit
decimal MCR address.
After three unsuccessful password attempts, the user will be logged out.
Most MMI commands may be executed by typing the first letter of each word
in the command separated by a space. Should two or more commands begin
with the same letter, type as many letters as it takes to differentiate one
command from another. The user may simply enter the entire command to
avoid confusion. The commands are not case-sensitive EXCEPT for the MMI
password (MCRLINK) and the The nine basic commands are:
• ALARM (A)
• CLEAR (C)
• DISPLAY (D)
• ESAM (E)
