Figure 1
Mini-Carrier Remote (example configuration)
Network
T1(1)
Product description
T1(1)
T1(2)
T1(2)
X
R
D
M
L
I
C
MCR remotes digital telephones, analog telephones, and analog trunks from
a Meridian 1 switch. The system is modular in that the local site uses one
Local Mini-carrier remote Interface card (LMI) and up to three Local
Mini-carrier remote Extender cards (LMXs). At the remote site, a single
Remote Mini-carrier Interface card (RMI), connected via one or two T1
carrier links to the LMI at the local site, controls up to eight standard IPE line
cards.
Mini-Carrier Remote Description, Installation, and Maintenance
LMI
L M X
Remote
site
X
X
X
D
A
U
L
L
T
C
C
Option 11C cabinet
Description
Page 11 of 150
Local
site
X
P
E
C
IPE shelf
