Nortel Meridian 1 Mini-Carrier Remote Description, Installation, And Maintenance page 98

Page 98 of 150 Installation and configuration
Figure 51
SET ESAM: END (SAVE) screen
ESAM Setup Menu:
1 - System Parameters
2 - Show Slot Parameters
3 - Set Slot Parameters
4 - Phone Parameters
5 - XUT Parameters
6 - Trunk Parameters
8 - Quit (No Save)
9 - End (Save)
9
Saving Values to Local EEPROM
MCR::>
P0914209 Standard 3.00 April 2000
SET SPAN (S S)
This command allows user to set the number of time slots used by the T1. Its
display is similar to Figure 52.
Note: All SPAN configuration values are stored on the LMI. If the user
replaces the LMI for any reason, all values set with the SET SPAN
command, and all commands on the Span setup menu, must be
reconfigured.
