Nortel Meridian 1 Mini-Carrier Remote Description, Installation, And Maintenance page 89

Figure 32
SET ALARM (S A) screen
MCR::>s a
Alarm 1 Threshold:
[Current Value - 5] - 5
Threshold Duration (in seconds) Min - 1
[Current Value - 10] - 10
Alarm 2 Threshold:
[Current Value - 4] - 4
Threshold Duration (in seconds) Min - 1
[Current Value - 10] - 10
Frame Slip Threshold (Min - 1
[Current Value - 100] - 100
Frame Slip Threshold Duration (in Minutes) Min - 1
[Current Value - 2] - 2
MCR::>
Figure 33
SET CONFIG (S C) screen
MCR::>s c
Equip Carrier 0
Equip Carrier 1
MCR::>
Figure 34
SET NAME (S N) screen
MCR::>s n
Change Near End Site Name
Min - E-3 Max - E-9
Min - E-3 Max - E-9
Max - 255)
SET CONFIG (S C)
This command equips or unequips the T1 carriers. Its display is similar to
Figure 33.
(YES or NO) Y
(YES or NO) Y
SET NAME (S N)
This command sets the name of the near end and remote sites. Its display is
similar to Figure 34.
(YES or NO) N
SET ESAM (S E)
This command configures the settings for ESAM protection. Its display is
similar to Figure 35.
Mini-Carrier Remote Description, Installation, and Maintenance
Installation and configuration
Max - 2148
Max - 218
Max - 1440
Page 89 of 150
