Meridian 1
Mini-Carrier Remote
Description, Installation, and Maintenance
Document Number: P0914209
Document Release: Standard 3.00
Date: April 2000
Year Publish FCC TM
Copyright ©1998–2000 Nortel Networks
All Rights Reserved
Printed in Canada
Information is subject to change without notice. Nortel Networks reserves the right to make changes in design
or components as progress in engineering and manufacturing may warrant. This equipment has been tested
and found to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC rules, and the
radio interference regulations of Industry Canada. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at their own expense.
SL-1 and Meridian 1 are trademarks of Nortel Networks.
Mini-Carrier Remote Description, Installation, and Maintenance

Advertisement

Table of Contents
loading

Related Manuals for Nortel Meridian 1 Mini-Carrier Remote

Summary of Contents for Nortel Meridian 1 Mini-Carrier Remote

  • Page 1 All Rights Reserved Printed in Canada Information is subject to change without notice. Nortel Networks reserves the right to make changes in design or components as progress in engineering and manufacturing may warrant. This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC rules, and the radio interference regulations of Industry Canada.
  • Page 3 Page 3 of 150 Revision history April 2000 Standard 3.00. This is a global document and is up-issued for X11 Release 25.0x. May 1998 Standard, release 2.00. Initial release. Mini-Carrier Remote Description, Installation, and Maintenance...
  • Page 4 Page 4 of 150 Revision history P0914209 Standard 3.00 April 2000...

  • Page 5: Table Of Contents

    Page 5 of 150 Contents About this document ..... . . Description ....... . System overview .
  • Page 6 Page 6 of 150 Contents Maintenance overview ........MMI Diagnostic tools .

  • Page 7: About This Document

    However, there are some additional mini-carrier specific commands that can be executed using the man-machine interface (MMI) terminal to specifically control mini-carrier equipment. Meridian 1 Mini-Carrier Remote system complies with Part 68 of the United States Federal Communication Commission (FCC) rules. Refer to “Regulatory approvals” on page 123.
  • Page 8 Page 8 of 150 About this document Maintenance describes how to perform routine administrative and maintenance functions and how to troubleshoot the Mini-Carrier Remote equipment and the mini-carrier link connections. It explains how to isolate problems, fix or replace defective equipment, and verify that the equipment is operating correctly after corrections or replacements have been made.

  • Page 9: Description

    Page 9 of 150 Description System overview The Mini-Carrier Remote (MCR) system, see Figure 1 on page 11, provides service for up to 128 analog and/or digital telephones over one or two T1 carrier links in a Meridian 1 system. Analog trunks at the remote site are also supported.
  • Page 10 Page 10 of 150 Description MCR consists of three circuit packs; two at the local site, the Local Mini-carrier Interface card (LMI) and Local Mini-carrier Extender card (LMX), and one at the remote site, the Remote Mini-carrier Interface card (RMI). At the local site, the LMI emulates two standard IPE line cards and can interface to the remote site via either one or two T1 carrier links.

  • Page 11: Product Description

    Description Page 11 of 150 Figure 1 Mini-Carrier Remote (example configuration) Local site L M X T1(1) T1(2) IPE shelf Network Remote site T1(2) T1(1) Option 11C cabinet Product description MCR remotes digital telephones, analog telephones, and analog trunks from a Meridian 1 switch.
  • Page 12 Page 12 of 150 Description The LMI and LMX are double-wide cards, each of which occupies two adjacent line card slots. They consist of a motherboard with circuitry and a small daughterboard that connects to the DS-30X interface of the adjacent slot.

  • Page 13: Physical Architecture

    Description Page 13 of 150 Remote site components The remote site consists of a Remote Mini-Carrier Interface card (RMI) and an Option 11 cabinet. The Option 11 cabinet contains the standard power supply and standard IPE line cards. The only new components at the remote site are the RMI and the RMI Multi-I/O cable assembly (NT5D87), see Figure 7 on page 19.
  • Page 14 Page 14 of 150 Description Figure 2 LMI (NT5D64 \ NT5D68) faceplate Local Mini-Carrier CAR ALM CAR ALM MAINT NT5D68AA Rlse 00 P0914209 Standard 3.00 April 2000...
  • Page 15 Description Page 15 of 150 Figure 3 LMX (NT5D65 \ NT5D69) faceplate Local Mini-Carrier MAINT NT5D65AA Rlse 00 Mini-Carrier Remote Description, Installation, and Maintenance...
  • Page 16 Page 16 of 150 Description Figure 4 RMI (NT5D67) faceplate Rem Mini Car I/F CAR ALM CAR ALM MAINT NORM ESAM NT5D67AA Rlse 00 P0914209 Standard 3.00 April 2000...
  • Page 17 Description Page 17 of 150 LMI Multi-I/O cable assembly The LMI Multi-I/O cable assembly (NT5D85), provides the local site interface between the LMI and the MMI, SDI, Alarm, and the T1 carrier links. See “LMI Multi I/O cable assembly” on page 127 for pin-out information. Figure 5 LMI Multi-I/O cable assembly (NT5D85) Alarm...
  • Page 18 Page 18 of 150 Description LMI/LMX Multi-I/O Cable Assembly The LMI/LMX Multi-I/O Cable Assembly (NT5D86) provides the local site interface between the LMI and up to three LMXs. This cable carries the DS-30X and MMI interfaces. See “LMI/LMX Multi-I/O cable assembly” on page 129 for pin-out information.
  • Page 19 Description Page 19 of 150 RMI Multi-I/O cable assembly RMI Multi-I/O cable assembly (NT5D87) provides the remote site interface between the RMI and the MMI, Alarm, and the T1 carrier links. See “RMI Multi-I/O cable assembly” on page 131 for pin-out information. Figure 7 RMI Multi-I/O Cable Assembly (NT5D87) Carrier 0 Carrier 1...

  • Page 20: Functionality

    Page 20 of 150 Description Functionality The Mini-Carrier Remote system can be user-configured to use only certain time slots, in this way allowing “drop-and-insert” channel banks to use the time slots not used by MCR. This allows customers to use LAN bridges via the remaining time slots to connect between local and remote LANs.
  • Page 21 Description Page 21 of 150 • employs a super set of the Man-Machine Interface (MMI) used in the Carrier Remote Interface product. The Mini-Carrier Remote system uses the same type of extensive carrier diagnostics that have proven useful on the Carrier Remote IPE product, •...
  • Page 22 Page 22 of 150 Description DIP switches Three cards have DIP switches that must be configured prior to card insertion. On the LMX, DIP switch settings identify the LMX’s position with respect to the LMI and RMI. DIP switch settings on the LMI and RMI determine binary daisy chain address, T1 line build-out, framing mode, terminal baud, and terminal settings.
  • Page 23 Re-insert the card and lock it in place with the ejector tabs. If the LEDs still do not flash three times, contact a sales representative about returning the card to Nortel for repair or replacement.
  • Page 24 Page 24 of 150 Description As long as the digital set is off-hook, it retains the time slot. An MCR user may place a call on hold, make a second call, and switch between calls. However, the call on hold is not occupying a time slot. If the user places the digital set on-hook while there is still a call on hold, the time slot is lost, but not the call.
  • Page 25 Also, if the local card receives a cardLAN message that is undefined, no attempt is made to answer that message. Should the existing Nortel line cards be updated such that they operate on an expanded cardLAN message set, the MCR system must also be updated.
  • Page 26 Page 26 of 150 Description When the T1 framer is configured for D4 operation the firmware uses bi-polar violations instead of CRC-6 errors. When using bi-polar violations, the total number of bi-polar violations are used as CRC-6 errors in the above calculations.
  • Page 27 Description Page 27 of 150 ESAM is intended to be used, primarily, in the case of an interruption in service from the T1 carrier links serving MCR systems. A two-position faceplate switch on the RMI, like the LMI, sets ESAM mode as always active or requires that ESAM switchover be determined through each location’s MMI configuration.
  • Page 28 Page 28 of 150 Description — the default setting for all trunks is disabled, • the XUT trunk type must be configured via the MMI as — none (default), — CO ground start, — CO loop start, or — CO direct-inward-dialing (DID) wink start immediate start delay start...
  • Page 29 Description Page 29 of 150 When a call comes into a trunk, all telephones that are on-hook with an unused line will ring and the lamp associated with the unused line will flash (if both lines are unused, the primary line’s lamp will flash). Telephones that are off-hook with an unused line will get a flashing lamp associated with the unused line and a warning tone.

  • Page 30: Physical Description

    Page 30 of 150 Description Physical description Local mini-carrier remote interface card The Local Mini-Carrier Remote Interface card (LMI) is a new circuit pack which resides in any two consecutive IPE card slots normally used for IPE circuit packs. The LMI consists of a motherboard and a daughterboard. The motherboard is a standard IPE-sized circuit pack with a double-wide faceplate.
  • Page 31 Description Page 31 of 150 Local mini-carrier remote extender card description The Local mini-carrier remote extender card (LMX) is a circuit pack residing in any two consecutive IPE card slots normally used for IPE circuit packs. The LMX consists of a motherboard and a daughterboard. The motherboard is a standard IPE-sized circuit pack with a double-wide faceplate.

  • Page 32: Engineering Guidelines

    Page 32 of 150 Description The T1 interface is capable of driving 655 feet without a repeater. A CSU is required for connection to the Public Switched Telephone Network (PSTN). Processor The processor is a 68000-based processor that controls all on-board functions.
  • Page 33 Description Page 33 of 150 NT8D11BC or Option 21, 21A, and NT5D64 NT5D65 NT8D11EC 21E CE/PE Module NTAK11AA or Option 11,11E NT5D68 NT5D69 NTAK11BB or Main Cabinet NTAK11BC NTAK12AA or Option 11, 11E NT5D68 NT5D69 11-19 NTAK12BB Expansion cabinet NTDK50BA Option 11C NT5D68 NT5D69...
  • Page 34 Page 34 of 150 Description • Second LMX • Third LMX If required by the customer, the following optional cables may be connected to the LMI Multi-I/O cable assembly (NT5D85): • NT7R87BA CSU Cable Kit (32ft). Purpose: Extends the T1 connection from the NT5D85 cable. •...
  • Page 35 Description Page 35 of 150 The opposite end of each RMI Multi-I/O cable assembly (NT5D87) provides connections for the following items: • First T1 Carrier Link • Second T1 Carrier Link • External Alarm • Man-Machine Interface (MMI) • Serial Data Interface (SDI) If required by the customer, the following optional cables can be connected to the RMI Multi-I/O cable assembly (NT5D87): •...
  • Page 36 Page 36 of 150 Description Table 3 Option 11 Hardware Compatibility with MCR Description NTAK11AA, BB, or BC Option 11, 11E Expansion Cabinet NTAK12AA, or BB Option 11, 11E Expansion Cabinet NTDK50BA Option 11C Main/Expansion Cabinet IPE Hardware MCR will only support a sub-set of the IPE card portfolio. Table 4 describes the IPE cards that are compatible with MCR.
  • Page 37 Description Page 37 of 150 Table 4 Remote IPE Card Compatibility Description Card Slots Slot Quantity NT8D02 Digital Line Card 1-10 NT8D03 Analog Line Card 1-10 NT8D09 Analog Line Card 1-10 NT8D14 Universal Analog Trunk 1-10 NT5D14 Line-side T1 Card Survivability Requirements If any of the T1 carrier links (or portion of them) fail during normal operation, MCR will provide “limited PBX-like”...
  • Page 38 Page 38 of 150 Description T1 Carrier Link Compatibility MCR requires standard DSX-1 Interface (B8ZS clear channel). MCR will support D4 or ESF framing protocols. Channel Service Units (CSUs) will be required at the host and remote sites for each T1 carrier link. These units are customer-provided (in some cases CSUs are supplied by the T1 providers).

  • Page 39: Mechanical Overview

    Description Page 39 of 150 Note: Use of M2250 Attendant Consoles is not supported. System CPU/Real Time Impact MCR consumes the same real time as if remote IPE cards were used in an IPE shelf at the host site. This means the real impact is calculated as if the cards were located at the host site.
  • Page 40 Page 40 of 150 Description Figure 8 Cabling for a single Local Mini-Carrier Interface card (LMI) Legend : L M X 2 F=Female gender connector M=Male gender connector Panel 9=9-pin connector 15=15-pin connector 25=25-pin conncetor L M X 1 Alarm NT7R86AA backplane L M X 0...
  • Page 41 Description Page 41 of 150 Figure 9 Cabling Local Mini-Carrier Interface cards (LMIs) in a daisy chain NT7R66AA LMI Multi-I/O cable assembly connection (NT5D85AA) LMI 31 As many For each LMI in as 32 the daisy chain, cards may there must be one be in one LMI Multi-I/O cable daisy...

  • Page 42: Power Requirement

    Page 42 of 150 Description Figure 10 Remote Mini-Carrier Interface cabling RMI Multi-I/O Cable (NT5D87AA) to optional Option 11 Alarm backplane/ NT7R86AA I/O Panel terminal NT7R66BA Remote C S U (customer Mini-Carrier -or Telco- Interface supplied) card (RMI) NT7R87BA C S U (customer No conenction -or Telco-...
  • Page 43 Description Page 43 of 150 Short Term: 0 o C to +70 o C Operating relative humidity: Normal: 10% to 95% (non-condensing) Short Term: 5% to 95% (non-condensing) Storage Temperature: -50 o C to +70 o C Relative Humidity: 5% to 95% (non-condensing) Temperature cycling The installed LMI, RMI, and LMX circuit packs withstand and operate normally after 3 temperature cycles according to IEC 69-2-14, Test Nb.
  • Page 44 Page 44 of 150 Description Mechanical shock - unpackaged (servicing) The LMI, RMI, and LMX circuit packs retain full functionality after being dropped, as described in TR-EOP-000063(NEBS) under the following conditions: From a 30 o tilt onto all faces and corners Mechanical shock - transportation bounce The packaged LMI, RMI, and LMX circuit packs retain full functionality after bounce testing according to IEC 68-2-29, Test Eb under the following...
  • Page 45 Description Page 45 of 150 Vibration endurance - transportation (packaged) The MCR circuit packs retain full functionality after vibration endurance testing according to IEC 68-2-6, Test Fc under the following conditions: Frequency swept automatically from 5 Hz to 100 Hz at the rate of one octave per minute with a constant acceleration of 0.5 g, repeated for 30 minutes on each of the three mutually perpendicular axes.

  • Page 46: Safety Requirements

    Page 46 of 150 Description No damage or malfunction occurs at up to +/- 20 kV of direct discharge. An indirect discharge of up to +/- 20 kV does not result in malfunction of the system (to adjacent equipment or connected cabling). Safety requirements •...

  • Page 47: Installation And Configuration

    Page 47 of 150 Installation and configuration This chapter describes the installation of Mini-Carrier Remote (MCR) as an integral part of Meridian 1 system Options 11, 11C, 11E, 21, 21A, 21E, 51, 51C, 61, 61C, 71, 81, and 81C. Note: Local-site installations are similar for all options. However, Option 11, 11C and 11E local sites require LMI and LMX cards which are different from cards for all other options.

  • Page 48: Quick Reference To System Installation

    Page 48 of 150 Installation and configuration Preinstallation procedures at both the local and remote sites include: • ordering T1 service from your telephone company, • preparing the site, • unpacking and inspecting the equipment, and • taking inventory of the MCR and system equipment. Local site installation procedures include: •...
  • Page 49 Installation and configuration Page 49 of 150 Local site • Take inventory of MCR equipment by comparing the received equipment against the shipping documents. Refer to Table 5, “Mini-Carrier Remote-unique hardware list,” for MCR component part numbers and descriptions. • Configure the NT5D64 (NT5D68 for Option 11, 11C and 11E) LMI DIP switches to set the appropriate card address and other parameters.

  • Page 50: System Installation

    Page 50 of 150 Installation and configuration • Connect Plug 3 of the NT5D86 LMI/LMX cable assembly to the 50-pin Amphenol connector for the second of the two line card slots occupied by LMX 2. (The 50-pin Amphenol connector for the first of the two line card slots is not used.) •...
  • Page 51 Installation and configuration Page 51 of 150 Preparing the sites When preparing a site, you must address environmental, structural, and electrical factors. These factors must be considered for the entire system, that is, Meridian 1 and MCR sites. This information is available in: •...
  • Page 52 Page 52 of 150 Installation and configuration Table 5 Mini-Carrier Remote-unique hardware list Component Description LMI (IPE) Local Mini-Carrier Interface card (LMI) for installation in IPE shelf line card slots. NT5D64 LMX (IPE) Local Mini-Carrier Extender card (LMX) for installation in IPE shelf line card slots.
  • Page 53 Installation and configuration Page 53 of 150 Table 5 Mini-Carrier Remote-unique hardware list Component Description 50-pin Amphenol RMI Multi-I/O This 2 ft. cable has a connector at one end that fits the I/O connector for the controller slot occupied by the RMI. The opposite end has Cable Assembly five connectors, which are for: NT5D87...
  • Page 54 Page 54 of 150 Installation and configuration Table 5 Mini-Carrier Remote-unique hardware list Component Description T1 CSU Cable Kit This cable kit provides: (Two per span) 1 cable (32-foot, RJ48 to RJ48) NT7R87BA 1 cable (sub-assembly, T1/CSU RJ48 to RJ48) 1 adapter (CPE to network, male DB15 to RJ48, NT7R93AA) 1 adapter (CPE to network, female DB15 to RJ48, NT7R93BA) 1 adapter (CPE to CPE, female DB15 to RJ48, NT7R93CA)
  • Page 55 Installation and configuration Page 55 of 150 Note 1: The NT7R87BA T1 CSU Cable Kit provided with the MCR equipment is used to connect the LMIs and RMIs to telco demarcation points (CSUs) at a distance of 32 feet (9.75 m). Install this cable kit, if applicable, between the CSU and the LMI at the local site and the RMI at the remote site as a preinstallation procedure.
  • Page 56 Page 56 of 150 Installation and configuration Installing the LMI The LMI can be installed when the system is powered up and running. Table 9, “LMI standard (default) switch settings,” on page 60, lists the default (factory provided) switch settings on the LMI. Verify the switch settings before installation ATTENTION! DO NOT ALTER JUMPER SETTINGS!
  • Page 57 Installation and configuration Page 57 of 150 Figure 11 Jumper settings on MCR circuit packs. EDGE OF FACEPLATE (Top of card ) Jumper Jumper Jumper Not used installed installed installed for LMX for RMI for LMI Set the DIP switches to specify the distance to the CSU, the MMI terminal baud and daisy-chain address.
  • Page 58 Page 58 of 150 Installation and configuration Table 6 shows the functions of LMI DIP switch 2 (SW2) at each position: Table 6 LMI SW2 at U23 functions Position Usage Binary daisy chain address OFF (not used) OFF = MMI End, ON = Not MMI end OFF = SDI End, ON = Not SDI end Each position’s default is OFF.
  • Page 59 Installation and configuration Page 59 of 150 Table 7 shows the function of LMI SW3 at each position: Table 7 LMI SW3 at U51 functions Position Usage T1 line build-out framing mode: ESF = OFF, D4 = ON baud 9600 = OFF, 2400 = ON terminal settings: N,8,1 = OFF, M, 7, 1 = ON not used Table 8 shows the settings for SW3, positions 1-3 to set various T1 Line...
  • Page 60 Page 60 of 150 Installation and configuration Table 9 lists the default settings for each LMI DIP switch position: Table 9 LMI standard (default) switch settings Switch positions Switch SW2 @ U23 OFF SW3 @ U51 ON Table 10 lists all possible addresses for an LMI. The card’s address is set with switch SW2 (@ U23), positions 1 through 6.
  • Page 61 Installation and configuration Page 61 of 150 Table 10 (Continued) LMI maintenance daisy chain addresses SW2 at U23 positions 1-5 (1 = ON, 0 = OFF) Address —continued— Mini-Carrier Remote Description, Installation, and Maintenance...
  • Page 62 Page 62 of 150 Installation and configuration Table 10 (Continued) LMI maintenance daisy chain addresses SW2 at U23 positions 1-5 (1 = ON, 0 = OFF) Address —end— Connecting cable assemblies to the LMI: Connect P1 of the NT5D85 LMI Multi I/O cable, see Figure 5 on page 17, to the 50-pin Amphenol connector for the first of the two line card slots occupied by the LMI.
  • Page 63 Installation and configuration Page 63 of 150 • If your CSU terminates to a RJ45 connector, directly connect the other end of the span cable to the CSU. • If your CSU terminates to a DB15 connector, connect the NT7R93AA adapter to the CSU and connect the span cable to the adapter.
  • Page 64 Page 64 of 150 Installation and configuration Install the local MMI terminal and T1 carrier link cables to the LMI Multi I/O cable assembly. See Figure 8 on page 40, for an illustration of the cable connections necessary for a single LMI system. For an illustration of the cable connections necessary to daisy chain the LMI’s terminal connection, see Figure 9 on page 41.
  • Page 65 Installation and configuration Page 65 of 150 Install the LMX into two consecutive line card slots in the same shelf or cabinet as the LMI. ATTENTION!! DO NOT ALTER JUMPER SETTINGS! The jumpers at J3 determine board-type and should never be removed or changed. Refer to Figure 11 on page 57 for the proper settings for these jumpers.
  • Page 66 Page 66 of 150 Installation and configuration Remove the front cover and all cards from the cabinet to make the cabinet lighter and to prevent card damage in case the cabinet drops during the installation process. Position the cabinet over the mounting bracket so that the bracket hook engages the slot at the rear of the cabinet.
  • Page 67 Installation and configuration Page 67 of 150 12 Disconnect the power cord from the wall outlet for the AC system or the DC power source for the DC system and reconnect the 6 AWG ground wire to the cabinet ground lug. 13 Reconnect the NTAK98AA supply power cord to the AC power outlet for an AC system or to the DC source for a DC system.
  • Page 68 Page 68 of 150 Installation and configuration Install line cards in slots 1 through 8. Install the local MMI terminal and T1 carrier link cables to the RMI Multi-I/O Cable Assembly (NT5D87). See Figure 10 on page 42. Pull the card locking devices away from the faceplate and insert the card into the card guides of a line card slot.
  • Page 69 Installation and configuration Page 69 of 150 — CSU is NOT configured for robbed-bit signaling — CSU accepts B8ZS zero substitution codes Unused carrier links should be configured as “unequipped” (using the set configuration command from the man machine interface terminal), to avoid a constant alarm condition.
  • Page 70 Page 70 of 150 Installation and configuration Table 14 shows the settings for RMI DIP switch 3, positions 1-3, to set various T1 Line Build-out lengths Table 14 T1 Line Build-out Table Position (1 = ON, 0 = OFF) LENGTH 534 - 655 feet 400 - 533 feet 267 - 399 feet...
  • Page 71 Installation and configuration Page 71 of 150 Main Distribution Frame connections Connect subscriber loop (tip and ring) cables to the cabinet, use 50-pin connectors J1 through J10. These cables have already been connected to the Main Distribution Frame (MDF) in the preinstallation preparation phase according to the instructions in “Cabling lines and trunks”...

  • Page 72: System Configuration

    Page 72 of 150 Installation and configuration Note: Ringing frequency selection is made with a three-way switch located to the left of the 4-position DIP switch at the top of the power supply. Typical North American setting is -150 V, 86 Vrms, and 20 Hz. System configuration The configuration and administration of the MCR at the Meridian 1 local site are identical to the standard Meridian 1 configuration and administration and...
  • Page 73 Installation and configuration Page 73 of 150 • Parity, character width, and stop bit are configured using SW3, position 6: — OFF = parity-None, character width-8, stop bit-1 (N, 8, 1) — ON = parity-Mark, character width-7, stop bit-1 (M, 7, 1) In this mode, the remote TTY or terminal becomes a Meridian 1 system TTY that can access overlays and perform system configuration, maintenance, and diagnostics, which are the same functions performed by the local Meridian 1...

  • Page 74: Host Mmi Interface

    Page 74 of 150 Installation and configuration MMI mode In the MMI mode, a terminal, or TTY, is connected to the local MMI port (P5 on the LMI Multi I/O cable) at the LMI or at the remote MMI port (P5 on the RMI Multi I/O cable) at the RMI.
  • Page 75 Installation and configuration Page 75 of 150 Table 18 MMI commands Command Description Alarm Disable. Disables all local and remote carrier alarms. Maint. LED lit. Alarm Enable. Enables all local and remote carrier alarms. Clear Alarm. Clears all local and remote carrier alarms. C A L Clear Alarm Log.
  • Page 76 Page 76 of 150 Installation and configuration Table 18 (Continued) MMI commands Command Description D P D Display Performance Distant. Displays distant-end performance counters for the specified carrier during the past hour. Display Status. Displays the status of the carriers on the near-end. D S D Display Status Distant.
  • Page 77 Installation and configuration Page 77 of 150 Table 18 (Continued) MMI commands Command Description S D D SET DATE DISTANT. Allows user to set or verify the date currently maintained by distant-end mini-carrier interface cards. SET ESAM. Allows user to configure the parameters of the Emergency Stand-Alone Mode.
  • Page 78 Page 78 of 150 Installation and configuration MMI Login Each MCR must be configured individually, even if the MCR resides in a daisy-chain configuration. To configure the MMI firmware for MCR, you must login to that particular MCR. Passwords must be upper case. All other commands are not case-sensitive.
  • Page 79 Installation and configuration Page 79 of 150 • HELP (HE) • HOST (HOS) • SET (S) • TEST (T) • QUIT (Q) An in-depth discussion of these commands follows, along with an example of the on-screen response generated by each. Our discussion will begin with the HELP command, which generates a listing of the 9 basic commands: HELP (HE, ?) If you enter ?, MMI will list available commands along with an explanation...
  • Page 80 Page 80 of 150 Installation and configuration Figure 13 ALARM ENABLE (A E) screen MCR::>a e Alarms Enabled MCR::> ALARM DISABLE (A D) This command will prevent the MCR system from asserting its alarm relay output while in alarm mode. Figure 14 ALARM DISABLE (A D) screen MCR::>a d...
  • Page 81 Installation and configuration Page 81 of 150 Figure 16 CLEAR ERROR (C E) screen MCR::>c e Error Counter Cleared MCR::> CLEAR ERROR DISTANT (C E D) This command resets MCR’s distant-end error counter to zero. Its display is similar to Figure 16. CLEAR ALARM LOG (C A L) This command removes all entries from MCR’s near end alarm log.
  • Page 82 Page 82 of 150 Installation and configuration DISPLAY [ALARM | CONFIG | STATUS | PERFORMANCE | HIST | MAP] [DIST] The DISPLAY commands list the condition of various aspects of the MCR system at the time the command is issued. DISPLAY ALARM LOG (D A) This command displays the contents of the near-end alarm log.
  • Page 83 Installation and configuration Page 83 of 150 Figure 20 DISPLAY CONFIG (D C) screen MCR::>d c MCR S/N Firmware Version V6.1C 14:56:17 03/17/98 Local Site Alarms Enabled: YES Link 0 Equipped Link 1 Equipped Alarm Level 1 Threshold Value E-5 Threshold Duration (in seconds) 10 Alarm Level 2 Threshold Value E-4 Threshold Duration (in seconds) 10...
  • Page 84 Page 84 of 150 Installation and configuration Figure 22 DISPLAY STATUS (D S) (at remote site) screen MCR::>d s MCR S/N testrmi Firmware Version V6.1D 13:51:01 03/21/98 Remote Site: RMI VERIFICATION Link Alarm Level 0 Link Alarm Level 0 MCR::> DISPLAY STATUS DISTANT (D S D) This command displays the current condition of each link controlled by the distant-end mini-carrier interface card.
  • Page 85 Installation and configuration Page 85 of 150 DISPLAY HISTORY (D H) This command shows the performance of the selected near-end mini-carrier remote interface card over the past 24-hour period. Its display is similar to Figure 24. Figure 24 DISPLAY HISTORY (D H) screen MCR::>d h Which Carrier? (0-1):0 MCR Interface History Performance Log...
  • Page 86 Page 86 of 150 Installation and configuration DISPLAY MAP (D M) This command displays the in-service or out-of-service status of all T1 channels in the MCR system. Its display is similar to Figure 25. Figure 25 DISPLAY MAP (D M) screen MCR::>d m : 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 2 2 2 2 2 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4...
  • Page 87 Installation and configuration Page 87 of 150 ESAM Never The ESAM Never command instructs MCR not to operate in the Emergency Stand-Alone Mode. Its display is similar to Figure 28. Figure 28 ESAM Never (E N) screen MCR::>e n MCR::> Note: This configuration setting can be overridden by the faceplate ESAM toggle switch.
  • Page 88 Page 88 of 150 Installation and configuration Figure 30 SET TIME (S T) screen MCR::>s t Current Time 01:22:06 9:26 Current Time 09:26:00 Update distant end site? (YES or NO) Y MCR::> SET TIME DISTANT (S T D) This command configures the time kept at the distant end by the system. Its display is similar to Figure 30.
  • Page 89 Installation and configuration Page 89 of 150 Figure 32 SET ALARM (S A) screen MCR::>s a Alarm 1 Threshold: Min - E-3 Max - E-9 [Current Value - 5] - 5 Threshold Duration (in seconds) Min - 1 Max - 2148 [Current Value - 10] - 10 Alarm 2 Threshold: Min - E-3...
  • Page 90 Page 90 of 150 Installation and configuration Note: ESAM configuration values are stored on the RMI. If the user replaces the RMI for any reason, all values set with the SET ESAM command, and all commands on the ESAM setup menu, must be reconfigured.
  • Page 91 Installation and configuration Page 91 of 150 Show Slot Parameters - This variation of the SET ESAM command shows the type of line card in each slot. Its display is similar to Figure 37. Figure 37 SET ESAM: SHOW SLOT PARAMETERS screen Current Cards in System: Slot 1 Existing Card Type - XDLC Slot 2 Existing Card Type - None...
  • Page 92 Page 92 of 150 Installation and configuration Figure 39 SET ESAM: PHONE PARAMETERS screen Enter Phone Port (0-15) Enter <cr> when done - 1 Provision Phone Port 1 (YES or NO) Y Enable Auto Hold (YES or NO) Y Enable Do Not Disturb (YES or NO) N Transfer Key [Current Value - 3] - 3 DN [Current Value - 6400] - 6400 Enter Phone Port (1-16)
  • Page 93 Installation and configuration Page 93 of 150 Figure 41 SET ESAM: PHONE PARAMETERS: XUT PARAMETERS: COMPANDING screen Enter Compander Type 1 - uLaw, 2 - aLaw, <cr> - No Change Slot 0 Existing Compander Type - uLaw New Type - 2 Type Now - aLaw XUT Setup Menu for XUT 1 - Companding 2 - 10PPS1 Make/Break Ratio...
  • Page 94 Page 94 of 150 Installation and configuration Figure 43 SET ESAM: PHONE PARAMETERS: XUT PARAMETERS: 10PPS2 MAKE/BREAK RATIO screen Enter 10PPS2 Make/Break Ratio [Current Value - 1] - 2 XUT Setup Menu for XUT 1 - Companding 2 - 10PPS1 Make/Break Ratio 3 - 10PPS2 Make/Break Ratio 4 - 20PPS Make/Break Ratio 9 - Return To Main Menu...
  • Page 95 Installation and configuration Page 95 of 150 Figure 45 SET ESAM: TRUNK PARAMETERS screen Enter Trunk Number (0-7) - 1 Trunk Setup Menu for Trunk 1: 1 - Trunk Type 2 - Balance Impedance 3 - Termination Impedance 4 - Dialing Speed 9 - Return To Main Menu Trunk type - This variation of the SET ESAM command allows the user to change the trunk type of the selected trunk from...
  • Page 96 Page 96 of 150 Installation and configuration Figure 47 SET ESAM: TRUNK PARAMETERS: BALANCE IMPEDANCE screen Enter Trunk Balance Impedance 1 - Complex, 2 - 600 ohms, <cr> - No Change Trunk 0 Existing Balance - Complex New Balance - 2 Balance Now - 600 Ohms Trunk Setup Menu for Trunk 1: 1 - Trunk Type 2 - Balance Impedance...
  • Page 97 Installation and configuration Page 97 of 150 Figure 49 SET ESAM: TRUNK PARAMETERS:DIALING SPEED screen Enter Dialing Speed 1 - 10PPS1, 2 10PPS2, 3 - 20PPS, 4 - DIGITONE, <cr> - No Change Trunk 0 Existing Dial Speed - 10PPS1 New Dial Speed - Dial Speed Unchanged Trunk Setup Menu for Trunk 1: 1 - Trunk Type...
  • Page 98 Page 98 of 150 Installation and configuration Figure 51 SET ESAM: END (SAVE) screen ESAM Setup Menu: 1 - System Parameters 2 - Show Slot Parameters 3 - Set Slot Parameters 4 - Phone Parameters 5 - XUT Parameters 6 - Trunk Parameters 8 - Quit (No Save) 9 - End (Save) Saving Values to Local EEPROM...
  • Page 99 Installation and configuration Page 99 of 150 Figure 52 SET SPAN (S S) screen MCR::>s s Span Setup Menu: 1 - Show Span Configuration 2 - Change Span Configuration 9 - End Enter Span Number (0-1) - 0 Current Configuration for Span 0 01 SYS 02 SYS 03 INS...

  • Page 100: Verifying Mini-Carrier Links At The Remote Site

    Page 100 of 150 Installation and configuration Verifying mini-carrier links at the remote site When all the MCR equipment is connected, all mini-carrier alarm LEDs may be turned OFF and the signaling across the link will work even though there may be a mismatch in mini-carrier links between the local and remote ends.
  • Page 101 Installation and configuration Page 101 of 150 Observe the mini-carrier alarm LEDs on the faceplate of the RMI. Initially, mini-carrier alarm LEDs for all equipped mini-carrier links should be ON due to Loss-of-Signal. The LED for carrier 0 should be turned OFF approximately 10 seconds after the patch cable for the selected carrier 0 is plugged into the RMI I/O cable connector for carrier 0.
  • Page 102 Page 102 of 150 Installation and configuration — If the LED for carrier 0 RMI (near end) is OFF but the RMI and the LMI cannot establish communication due to a carrier alarm condition on the LMI (distant end), the D S command will show “No Alarm”...
  • Page 103 Installation and configuration Page 103 of 150 • Threshold Duration—Mini-Carrier signal monitoring duration (1 second to 3600 seconds) to detect bit error rate (CRC and BIPV) exceeding the threshold. The error counter is updated every second for the length of the threshold duration. •...
  • Page 104 Page 104 of 150 Installation and configuration P0914209 Standard 3.00 April 2000...

  • Page 105: Maintenance

    The MCR circuit packs are field replaceable only. They are NOT to be serviced in the field. • In the event of failure, the circuit packs must be returned to Nortel Networks for repair or disposal. • All ESAM configuration data are stored on the RMI. If the user replaces the RMI for any reason, all data set with the SET ESAM command, and all commands on the ESAM setup menu, must be reconfigured.

  • Page 106: Maintenance Overview

    Page 106 of 150 Maintenance Maintenance overview MCR maintenance deals with two types of problems: • installation, and • operation. Installation problems are those problems that occur with MCR during the installation of an entire Meridian 1 system or during the addition of MCR to an existing system.

  • Page 107: Mmi Diagnostic Tools

    Maintenance Page 107 of 150 MMI Diagnostic tools Hardware diagnostic tools System hardware diagnostic tools consist of: • card self-tests • LED indicators, and • enable/disable switches. Card self-tests Mini-Carrier Remote cards automatically perform a self-test • when inserted into an operating system module, •...
  • Page 108 Page 108 of 150 Maintenance Mini-Carrier Remote LED indicators Both the Local Mini-Carrier Remote Interface card and the Remote Mini-Carrier Remote Interface card have LED indicators on the front panel. These are: • Card LED—red LED indicating card status. If the LED is ON, the card may be faulty or disabled.
  • Page 109 Maintenance Page 109 of 150 Fault isolation/correction using MMI maintenance commands You can perform testing and troubleshooting of the Mini-Carrier Remote from a local or a remote MMI terminal or TTY by typing MMI commands on the terminal without loading system diagnostic programs (overlays). These commands provide current equipment status, invoke card testing, check equipment performance, and print messages from log files.
  • Page 110 Page 110 of 150 Maintenance Figure 55 DISPLAY STATUS DISTANT screen MCR::>d s d MCR S/N Firmware Version V6.1C 14:56:26 03/17/98 Local Site: Link Alarm Level 0 Link Alarm Level 0 LMX 0 S/N NNTM1831R0LV F/W V6.1C Status - NORMAL LMX 1 S/N NNTM1831TE22 F/W V6.1C Status - NORMAL LMX 2 S/N NNTM1831TE25 F/W V6.1C Status - NORMAL MCR::>...
  • Page 111 Maintenance Page 111 of 150 Procedure 2 Checking the carrier performance status The Remote Mini-Carrier Interface card can display carrier performance information for the current hour and for the last 24 hours. The data and total errors are shown separately in the report for both the local and the remote site. The report displays the bit error rate, loss of frame count, loss of signal, alarm indication count, and frame slip count.
  • Page 112 Page 112 of 150 Maintenance Figure 57 DISPLAY HISTORY (D H) screen MCR::>d h Which Carrier? (0-1):0 MCR Interface History Performance Log For Carrier Number 0 01:17:52 02/06/98 Hour Errored Bursty Unavailable Loss Frame Frame Slip Error Ending Seconds Seconds Seconds Seconds Seconds...
  • Page 113 Maintenance Page 113 of 150 The performance criteria for which these counts are maintained are as follows. • Errored seconds - one or more CRC-6 errors or one or more out-of-frame errors during the second • Bursty seconds - More than one and less than 320 CRC-6 errors during the second.
  • Page 114 Page 114 of 150 Maintenance Procedure 3 Testing the carriers After checking the carrier status report and performance log and finding that one or more carriers is faulty, proceed to isolate the cause by testing the carriers using the command. The screen TEST (T) displayed by the command is similar to Figure 58.
  • Page 115 Maintenance Page 115 of 150 failures, if any, occurred during the test. If the counter reaches 65,000, it will remain there until reset. Test 1 listed above is a test that can be run while the MCR Circuit Pack is on line. The On-line Carrier test will indicate whether or not there is a failure, but does not indicate where the failure has occurred.
  • Page 116 Page 116 of 150 Maintenance A verbose mode is also available for the user. This mode provides a display of in-progress test results and allows the user to see exactly which port, or ports are not passing the test. The command to activate the verbose mode is TEST VERBOSE (T V).
  • Page 117 Maintenance Page 117 of 150 Figure 60 Off-line Near end loopback test Loopbacked Test Vector T1 Traffic T1 Traffic N e a r M C R C a r d External Network F a r M C R C a r d This test can also be issued with a distant modifier.
  • Page 118 Page 118 of 150 Maintenance Off-line Network Loopback Test Test 4, the Off-line Network Loopback test assumes that a loopback is configured somewhere in the network. Test data is generated at the near end MCR and received at the near end. You can perform the Off-line Network Loopback test on the near end or the distant end.
  • Page 119 Page 119 of 150 Appendix A: Man-Machine Interface (MMI) commands The appendix provides a list and brief explanation of the man-machine interface (MMI) commands available to users through the RS-232 terminal located at the local site. Table 20 MMI commands Command Description Alarm disable.
  • Page 120 Page 120 of 150 Appendix A: Man-Machine Interface (MMI) commands Table 20 (Continued) MMI commands Command Description Display configuration. Displays current configuration of the near-end mini-carrier interface cards. D C D Display configuration distant. Displays current configuration of the distant-end mini-carrier interface cards. Display history.
  • Page 121 Appendix A: Man-Machine Interface (MMI) commands Page 121 of 150 Table 20 (Continued) MMI commands Command Description —continued— Log in. Logs into the MMI terminal when the system has one Mini-Carrier Interface card. The password is MCRLINK. If logged in, typing L and an incorrect password will log out user from MCR MMI system.
  • Page 122 Page 122 of 150 Appendix A: Man-Machine Interface (MMI) commands Table 20 (Continued) MMI commands Command Description Test distant. Allows user to select 1 of 5 tests to be run on the specified carrier link at the distant end. Test verbose. Instructs system to display error reports while tests of specified carrier link at the near end are in-progress.

  • Page 123: Regulatory Notices

    Page 123 of 150 Appendix B: Regulatory approvals This appendix provides the general information that is supplied to the user as required by the FCC. The general information that should be provided: • The FCC registration number and a list of all ports that connect to the network •...
  • Page 124 Facility Interface Code: 04DU9-DN Service Order Code: 6.0P USOC Jack Type:RJ48C If trouble is experienced with the Meridian 1 Mini-Carrier Remote equipment, please contact your authorized distributor or service center in the U.S.A. for repair/warranty information. There is no user repair involved with this equipment.
  • Page 125 Appendix B: Regulatory approvals Page 125 of 150 Allowing Meridian 1 Mini-Carrier Remote equipment to operate without proper answer supervision signals is a violation of FCC Rules, Part 68. Therefore: • This equipment returns proper answer supervision signals to the Public Switched Telephone Network (PSTN) when: —...
  • Page 126 Page 126 of 150 Appendix B: Regulatory approvals Repairs to certified equipment should be coordinated by a representative designated by the supplier. Any repairs or alterations made by the user to this equipment, or equipment malfunctions, may give the telecommunications company cause to request the use to disconnect the equipment.

  • Page 127: Lmi Multi I/O Cable Assembly

    Page 127 of 150 Appendix C: Pin-outs LMI Multi I/O cable assembly Table 21 associates the LMI Multi-I/O cable assembly (NT5D85) connectors to their correct connections. Table 21 LMI Multi-I/O cable assembly (NT5D85) connections CONN. CONNECTS TO LMI backplane I/O connector T1 Carrier Link 0 T1 Carrier Link 1 alarm contact closure...
  • Page 128 Page 128 of 150 Appendix C: Pin-outs Table 22 LMI Multi-I/O cable assembly (NT5D85) pin-out WIRE COLOR FROM SIGNAL P1 - 21 P2 - 3 T1P0RXT P1 - 46 P2 - 11 T1P0RXR P1 - 22 P2 - 1 T1P0TXT P1 - 47 P2 - 9 T1P0TXR...

  • Page 129: Lmi/Lmx Multi-I/O Cable Assembly

    Appendix C: Pin-outs Page 129 of 150 —continued— P1 - 44 P5 - 9 MMIARB1 P1 - 45 P5 - 8 MMIARB2 P1 - 39 P6 - 3 SDIRXD P1 - 40 P6 - 2 SDITXD P1 -38 P6 - 5 P1 - 43 P6 - 7 MMIARB0...
  • Page 130 Page 130 of 150 Appendix C: Pin-outs Table 24 LMI/LMX Multi-I/O cable assembly (NT5D86) pin-out WIRE COLOR FROM SIGNAL P1 - 9 P2 - 10 DS30XMXTX0+ P1 - 34 P2 - 35 DS30XMXTX0- P1 - 10 P2 - 9 DS30XMXRX0+ P1 - 35 P2 - 34 DS30XMXRX0-...

  • Page 131: Rmi Multi-I/O Cable Assembly

    Appendix C: Pin-outs Page 131 of 150 —continued— P1 - 18 P5 - 9 DS30XMXRX2+ P1 - 43 P5 - 34 DS30XMXRX2- P1 - 19 P5 - 12 COMTXD2+ P1 - 44 P6 - 37 COMTXD2- P1 - 20 P6 - 11 COMRXD2+ P1 - 45 P6 - 36...
  • Page 132 Page 132 of 150 Appendix C: Pin-outs Table 26 RMI Multi-I/O cable assembly (NT5D87) pin-out WIRE COLOR FROM SIGNAL P1 - 19 P2 - 3 T1P0RXT P1 - 43 P2 - 11 T1P0RXR P1 - 21 P2 - 1 T1P0TXT P1 - 45 P2 - 9 T1P0TXR...
  • Page 133 Appendix C: Pin-outs Page 133 of 150 —continued— P1 - 38 P5 - 5 P1 - 37 P5 - 7 MMIARB0 P1 - 39 P5 - 9 MMIARB1 P1 - 41 P5 - 8 MMIARB2 P1 - 9 P6 - 3 SDIRXD P1 - 33 P6 - 2...

  • Page 134: T1 Csu Cable Kit Adapters

    Page 134 of 150 Appendix C: Pin-outs T1 CSU Cable Kit adapters CPE to Network male (NT7R93AA) Table 27 is the pin-out table for the CPE to Network male DB15 to RJ48 adapter of the T1 to CSU Cable Kit (NT7R87BA). Table 27 CPE to Network male DB15 to RJ48 adapter pin-out WIRE...
  • Page 135 Appendix C: Pin-outs Page 135 of 150 CPE to Network female (NT7R93BA) Table 28 is the pin-out table for the CPE to Network female DB15 to RJ48 adapter of the T1 to CSU Cable Kit. Table 28 CPE to Network female DB15 to RJ48 adapter pin-out WIRE COLOR FROM...
  • Page 136 Page 136 of 150 Appendix C: Pin-outs CPE to CPE female (NT7R93CA) Table 28 is the pin-out table for the CPE to CPE female DB15 to RJ48 adapter of the T1 to CSU Cable Kit. Table 29 CPE to CPE female DB15 to RJ48 adapter pin-out WIRE COLOR FROM...

  • Page 137: Index

    Page 137 of 150 Index Multi-I/O cable assembly (NT5D87), 19, 35, 53, 131 AC, 67, 71 DISPLAY ALARM LOG (D A L), 82 ACD (Automatic Call Distribution) DISPLAY ALARM LOG DISTANT (D A L blocking, 21, 37 D), 82 functionality, 21 Emergency Stand-Alone Mode (ESAM), 26, hold, 23 time slot assignment, 23...
  • Page 138 Page 138 of 150 Index local site, 40 LMI-LMX Multi-I/O cable assembly B8ZS, 20, 38 (NT5D86), 12, 13, 18, 33, 35, 39, 48, CSU, 63, 69 encoding, 21 local site, 12, 18, 35, 39, 40, 49, 53, 55 baud, 21, 22, 49 MMI Cable Kit (NT7R66BA), 34, 35, 53, 69 DIP switch setting, 57, 59, 67 remote site, 10, 13, 19, 34, 48, 50, 53, 55, 100...
  • Page 139 Index Page 139 of 150 configuration, 63, 69 CSU, 30, 32, 34, 38, 54, 55, 57, 62, 68, 70 configuring, 102 B8ZS, 63, 69 determining performance, 111 robbed-bit signaling, 63, 69 determining status, 110, 111 testing, 77, 108, 109, 110, 118, 121 unused, 63, 69 D4, 20, 21, 26, 38, 59, 69 CLEAR commands, 80–81...
  • Page 140 Page 140 of 150 Index DIP switches, 22 DISPLAY commands, 82–86 daisy chain DISPLAY ALARM LOG (D A L), 75 cabling, 64 DISPLAY ALARM LOG DISTANT (D A L daisy chain address, 58, 60, 64 D), 75 DISPLAY CONFIG DISTANT (D C D), 83 address, 22 DISPLAY CONFIGURATION (D C), 75 baud, 49, 57, 59...
  • Page 141 Index Page 141 of 150 Emergency Stand-Alone Mode compatibility, 38 trunks, 94 telephones supported, 38 Emergency Stand-Alone Mode (ESAM), 20, 26, traffic capacity, 37 blocking, 37 alarm, 76 environmental considerations alarm level 2, 26, 87 shipping and seismic considerations call transfer, 27 mechanical shock commands, 86–87 packaged, 43...
  • Page 142 Page 142 of 150 Index Option 11 (NT5D68), 14 ESF, 20 Remote Mini-carrier Interface card (NT5D67), LAN, 20 LED indicators, 13, 21, 22 fault detection, 21 Man-Machine Interface (MMI), 22 fault isolation and correction man-machine interface (MMI), 21 MMI maintenance commands, 109 man-machiune interface (MMI), 21 feature keys Meridian Digital Telephone support, 26...
  • Page 143 Index Page 143 of 150 overview, 48 LMI Multi-I/O cable assembly (NT5D85), 13, 17, overview, 47, 50 34, 48, 49, 52, 54, 55, 127 preinstallation alarm connection, 17, 30, 33, 52 NT7R87BA T1 CSU Cable Kit, 55 connections, 62 remote site, 50 daisy chain, 40 site preparation, 51 pin-out, 128...
  • Page 144 Page 144 of 150 Index DIP switches, 22 multiple LMIs per, 21 processor, 30 Man-Machine Interface (MMI), 22, 109, 111 signaling interface, 30 man-machine interface (MMI), 21, 52, 53, 58, 108, T1, 30 109, 111 T1 line build-out, 49 DIP switch setting, 58 terminal settings, 49 port local site, 11, 18, 20, 22, 25...
  • Page 145 Index Page 145 of 150 81, 111 SET CONFIGURATION (S C), 76, 108 CLEAR MEMORY (C M), 75, 81 SET DATE (S D), 76, 88 CLEAR MEMORY DISTANT (C M D), SET DATE DISTANT, 88 75, 81 SET DATE DISTANT (S D D), 77 DISPLAY commands, 82–86 SET ESAM (S E), 77, 89 DISPLAY ALARM LOG (D A L), 75, 82...
  • Page 146 Page 146 of 150 Index Test 5, 115, 118 Off-line Network Loopback Test (Test 4), 115, 118 TEST VERBOSE (T V), 116 Online Carrier Test (Test 1), 115, 116 TEST DISTANT (T D), 77 operating and storage considerations, 42 TEST VERBOSE (T V), 77 operating relative humidity, 43 MMI Diagnostic tools, 107 operating temperature, 42...
  • Page 147 Index Page 147 of 150 power requirements, 42 quick reference, 50 power supply, 71 verifying links, 100 precautions remote site installation, 55 antistatic, 51 remote-site grounding, 51 cabling, 41 primary line feature key re-order, 28 ESAM, 27 blocking, 24 processor, 30, 31, 32 ESAM, 29 product description, 11 repair and replacement, 105...
  • Page 148 Page 148 of 150 Index SET commands, 87–99 unpackaged (servicing), 44 SET ALARM (S A), 76 vibration endurance, 45 SET CONFIGURATION (S C), 76, 108 operational, 44 SET DATE (S D), 76 transportation SET DATE DISTANT (S D D), 77 packaged, 45 SET ESAM (S E), 77 vibration resonance search, 44...
  • Page 149 Index Page 149 of 150 telephones analog, 9, 10, 11, 38 T1, 13, 20, 30, 32, 47 ESAM-compatible models, 26 CSU, 32, 34, 38 supported models, 38 framing mode telephones supported, 38 D4, 20, 21, 26, 38, 59, 69 temperature cycling, 43 ESF, 20, 21, 59 terminal settings, 49 T1 carrier link...
  • Page 150 Page 150 of 150 Index time 10PPS2 Make/Break Ratio, 93 SET TIME (S T), 77 20PPS Make/Break Ratio, 94 SET TIME DISTANT (S T D), 77 Companding, 92 setting, 87, 88 trunks, 27 time slots, 24, 38 ESAM, 27 assignment hold, 23, 24 blocking, 37 SET SPAN (S S), 77, 98, 121...
  • Page 152 Description, Installation, and Maintenance Copyright ©1998–2000 Nortel Networks All Rights Reserved Information is subject to change without notice. Nortel Networks reserves the right to make changes in design or components as progress in engineering and manufacturing may warrant. This equipment has been...

Table of Contents
