1. Introduction

This document describes the functionality of the HMC1023LP5E 6th order Low Pass Filter
Evaluation Kit, and provides high level instructions for using the Kit. This kit includes PC
compatible software that generates a Graphical User Interface (GUI) allowing the user to read
from and write to all device registers, set gain levels, program filter bandwidth and save &
recall device configurations.
Note: For most up-to-date software download and information please visit
navigate to HMC1023LP5E page.

1.1 Hittite LPF Evaluation Kit Contents

1.1.1

Hardware

Item
HMC1023LP5E Evaluation Board
USB Interface Board
6' USB A Male to USB B Male Cable
CD ROM (Contains User Manual and software)
1.1.2

Software

HMC1023LP5E Eval Software
• Used to enable communication between a PC and HMC1023LP5E
• Enables users to observe full functionality and performance of HMC1023LP5E
Note: All software can be downloaded from www.hittite.com, or shipped on a CD along with other
contents of the kit.

2. Operating Environment

The HMC1023LP5E Evaluation Kit is designed for use in a laboratory setting at ambient room
temperature (25 °C) and is not protected against moisture. The USB Interface Board has an
ESD rating of ±3000V, however the HMC device may have a lower rating (check the product's
data sheet for its specific ESD rating). Use appropriate ESD procedures and precautionary
measures when handling all electronic hardware.
