UNIT DATA

4.2.3 DC fuses

Assembly kit
Size
(holders and fuses)
14 14U42EG-3W00
16 16U42GH-3W00
18 18U420H-3W00
19 19U42HR-3W00
20 20U420R-3W00
22 22U420R-3W00
24 24U42RU-5W00
26 26U420U-5W00
27 27U420U-5W00
28 28U420W-5W00
29 29U420W-5W00
30 2 x 27U420U-5W00
33 2 x 29U420W-5W00
34 2 x 29U420W-5W00
38 3 x 29U420W-5W00
Table 11: DC fuses

4.2.3.1 Alternative DC-fusing

Fuse holder with protec-
Size tive cover for NH00 and
NH000
14 2 x 0090574-0001
16 2 x 0090574-0001
18 2 x 0090574-0001
20 2 x 0090574-0001
22 2 x 0090574-0001
24 2 x 0090574-0001
Table 12: Alternative DC-fusing
Due to the gripping lugs, the protective cover of 0090574-0001 can not be used. The compatible
1)
microswitch has the following material number: 0090278-0001.
32
Fuse
2 x 0090249-5419
2 x 0090249-5459
2 x 0090249-5519
2 x 0090249-5529
4 x 0090249-5479
4 x 0090249-5529
2 x 0090249-5609
2 x 0090249-5639
2 x 0090249-5659
2 x 0090249-5679
2 x 0090249-5689
4 x 0090249-5659
6 x 0090249-5659
4 x 0090249-5689
6 x 0090249-5689
Fuse
2 x 009025H-3459
2 x 0090256-4531
2 x 009025H-3559
2 x 009025H-3559
2 x 00902564581 /
0090256-4621
2 x 009025H-4651
1)
Fuse body in
U in
mm V DC
Ø27 x 60.3 660
Ø27 x 60.3 660
Ø27 x 60.3 660
Ø27 x 60.3 660
Ø27 x 60.3 660
Ø27 x 60.3 660
129 x 60 750
129 x 60 750
129 x 60 750
129 x 75 750
129 x 75 750
129 x 60 750
129 x 60 750
129 x 75 750
129 x 75 750
U in
Fuse body
V DC
NH000 690
NH000 700
NH000 690
NH000 690
NH000 700
NH00 690
I in
A
25
50
80
100
63
100
250
350
400
500
630
400
400
630
630
I in
A
50
100
125
125
200 / 315
400
