- Page 1 Installation and Operating Instructions VideoTerminal 2600 ..
-
Page 3: Table Of Contents
Contents Device description ....................5 Installation ......................6 Removing glass cover ..................7 Operation ......................7 Normal conversation mode ................8 Accepting a call ................8 Enforcement function..............9 Ending a call ................. 9 Deactivating/activating ringing tone ..........10 Switching on camera image ............10 Changing display of colour camera ..........11 Switching functions ..............11 Opening door ................11 Switching light (in conjunction with a switching actuator)....11... -
Page 5: Device Description
Device description The VideoTerminal is a home station from the Gira door communication system with a large TFT colour display and a convenient hands-free speech function. The VideoTerminal is operated with the backlit operating button for turning and pressing and the four function buttons. -
Page 6: Installation
Installation Wire lengths to power supply The maximum wire length between the power supply and the VideoTerminal is dependent on the wire diameter used. It is 50 m for 0.6 mm diameter and 80 m for 0.8 mm diameter If these maximum wire lengths are exceeded, malfunctioning of the VideoTerminal may occur. -
Page 7: Removing Glass Cover
Removing glass cover To remove, the glass cover is pulled off toward the front using the removal suction cups provided. Operation The VideoTerminal is operated with the 4 function buttons and the backlit operating button. VideoTerminal 1 Display 2 "Menu" button Briefly pressing the button activates/deacti- vates the menu (see Page 12). -
Page 8: Normal Conversation Mode
Normal conversation mode Accepting a call ✓ When a call is received, the operating but- ton flashes green for two minutes. If the call comes from a video door station, the display is automatically switched on and shows the camera image. The number of cameras shown is dis- played. -
Page 9: Enforcement Function
Enforcement function If the background noises at the door station are so loud that automatic switching of the speech direction is not guaranteed, the enforcement function can be activated: 1. This is achieved by pressing the operating button while speaking. While the button is being pressed, is it only possible to speak from the VideoTerminal to the door station. -
Page 10: Deactivating/Activating Ringing Tone
Deactivating/activating ringing tone Only deactivate the ringing tone if necessary Only deactivate the ringing tone in special cases. Otherwise, your run the risk of not hearing the ringing in an emergency, for example. 1. Press the button to deactivate the ringing tone. ✓... -
Page 11: Changing Display Of Colour Camera
Changing display of colour camera If several colour cameras are installed, it is possible to switch between the respec- tive camera images with the operating button: 1. Turning the operating button selects the respective next camera. With more than two cameras: Turning clockwise = next camera, Turning anticlockwise = previous camera. -
Page 12: Structure Of Menu Interface
Structure of menu interface 1. Briefly press the Menu button to open the menu. Menu Opening menu with automatic door opener activated or ringing tone deactivated If the automatic door opener is activated or the ringing tone is deactivated (operating button lights up red), first the status display appears after briefly pressing the Menu button (see Page 15). -
Page 13: Camera Selection
Camera selection In the "Camera selection" menu all C a m e r a s e l e c t i o n assigned colour cameras are displayed. C a m e r a 1 C a m e r a 2 The desired camera can be selected and switched on by turning and pressing the operating button. -
Page 14: Switching
Switching In the "Switching" menu assigned switch- S w i t c h i n g ing actions can be triggered. The desired S w i t c h i n g a c t i o n S w i t c h i n g a c t i o n switching action can be selected and trig- S w i t c h i n g a c t i o n gered by turning and pressing the operat-... -
Page 15: Status Display
Status display If the automatic door opener is activated or S t a t u s the ringing tone is deactivated (the operat- A u t o m a t i c d o o r o p e n e r R i n g i n g t o n e d e a c t i v a t i o n ing button lights up red), first the status display appears after briefly pressing the... -
Page 16: Setting Ringing Tone Volume
Setting ringing tone volume In the "Ringing tone volume" menu the R i n g i n g t o n e v o l u m e ringing tone volume of the VideoTerminal can be adjusted in 8 steps by turning and pressing the operating button. -
Page 17: Brightness - Contrast - Colour
Brightness - contrast - colour Selecting camera beforehand The colour camera must be selected before one of the menu items "Brightness", "Contrast" or "Colour" is marked. If no camera has been selected, the message "No camera selected" appears. In the "Brightness", "Contrast" or "Colour" B r i g h t n e s s C a m e r a 1 menu, the respective parameters can be... -
Page 18: Commissioning Menu
Commissioning menu To open the Commissioning menu: 1. Press the programming button on the control device for 3 seconds to start the programming mode. ✓ The operating button of the VideoTerminals flashes red. 2. Briefly press the Menu button to open the Commissioning Menu menu. -
Page 19: Frequency
Frequency Select camera beforehand Before the menu item "Frequency" is selected, a colour camera must be selected. If no camera has been selected, the message "No camera selected" appears. The optimum frequency of the video signal F r e q u e n c y C a m e r a 1 of the currently active transfer path is set for fine-tuning of the video signal between... -
Page 20: Lighting
Lighting Selecting camera beforehand Before the menu item "Lighting" is selected, a colour camera must be selected. If no camera has been selected, the message "No camera selected" appears. Factory setting: auto L i g h t i n g C a m e r a 1 The behaviour of the field of view illumina- a u t o... -
Page 21: Display
Display Factory setting: on D i s p l a y o f f Here it is specified whether the VideoTer- minal can be switched on with the Menu button. off: The VideoTerminal is only switched on after a door call. Manual switch-on with the Menu button is not possible with this setting on: The VideoTerminal is switched on after... -
Page 22: Assign
Assign In the "Assign" menu the VideoTerminal is A s s i g n assigned components from the door com- A s s i g n c a l l P r o v i d e i n t e r n a l c a l l munication system (e.g. -
Page 23: Factory Setting
Factory setting Here the settings of the VideoTerminals are F a c t o r y s e t t i n g reset to the factory settings. D i s p l a y p a r a m e t e r s D e l e t e c a m e r a s D e l e t e c a l l a s s i g n m e n t D e l i v e r e d s t a t e... -
Page 24: Version
Version The current software version of the Video- V e r s i o n Terminal is displayed here. 0 3 . 0 0 - C P U 0 1 . 0 0 - G I F 0 3 . 0 0 - K B A 0 3 . -
Page 25: Assigning Door Station To Videoterminal
If you cannot access the home during commissioning, you can also assign the VideoTerminal via a connected floor-call button: In this case the VideoTerminal behaves like a home station of the Gira door commu- nication system. The assignment with a floor call button is described in the system... -
Page 26: Assigning Home Station To Videoterminal
Assigning home station to VideoTerminal You can implement the so-called internal call function with the optional call button for home stations. A voice connection between the home station and the VideoTer- minal can be established via the internal call. To assign a home station call button to the VideoTerminal, proceed as follows: 1. -
Page 27: Assigning Videoterminal To A Home Station
Assigning VideoTerminal to a home station The so-called internal call function can be realised with the VideoTerminal. A voice connection between the VideoTerminal and the home station can be established via the internal call. Please proceed as follows to assign the VideoTerminal to another home station: 1. -
Page 28: Assigning Switching Actuator To A Videoterminal
Assigning switching actuator to a VideoTerminal 1. Press the "System prog." button on the control device for 3 sec. to start programming mode. ✓ The LED of the last set operating mode flashes at the switching actuator. 2. Press the "Function" button on the switching actuator several times until the LED of the desired operating mode flashes. -
Page 29: Technical Data
Technical data Dimensions: 182 x 240 x 52 mm (W x H x D) Power supply: 24 V DC ± 10%, 700 mA Ambient temperature: -5°C to +40°C Protection type: IP 20 Connections: 2 screw terminals for 2-wire bus 2 screw terminals for floor-call button 2 screw terminals for additional supply 1 system bus connector strip (6-pole) Colour system:... -
Page 30: Warranty
Warranty We provide a warranty in accordance with the statutory requirements. Please send the device postage paid with an error description to our central cus- tomer service centre. Gira Giersiepen GmbH & Co. KG Service Center Dahlienstraße 12 D-42477 Radevormwald... - Page 32 Gira Giersiepen GmbH & Co. KG Electrical Installation Systems Postfach 1220 42461 Radevormwald Germany Phone +49 (0) 2195 / 602 - 0 Fax +49 (0) 2195 / 602 - 119 www.gira.com info@gira.com...
