- Page 1 Mounting and Operating Instructions Indoor station with handset, Standard 1281 ..
- Page 3 Device description The Indoor station with handset, Standard is part of the Gira door communication system and consists of the fol- lowing components: 1 Handset insert 2 Audio connection cable 3 Door communication bus coupler 4 Cover frame (not included in scope of supply)
- Page 4 Mounting Attention Installation and mounting of electrical devices may only be carried out by a qualified electrician. The Indoor station with handset, Standard is installed in two common flush-mounted panel boxes. Please install the components of the Indoor station, Standard in the following order: 1.
- Page 5 Start-up Once you have installed all of the devices (door and indoor stations, control unit etc.), you can start up the door communication system. Start-up is described in the system manual included with the control unit. Operation Accepting a call If an incoming call is present, you simply pick up the handset and speak to the person at the outdor station, without the need to press any other buttons.
- Page 6 Setting the call tone volume 1. Pick up the handset. 2. Press the button for 3 seconds. ✓ The next-highest call tone volume is output in the handset with reduced handset volume. There are five volume levels in total. 3. Press the button for 3 seconds again to set the next volume level.
- Page 7 The warranty is provided in accordance with statutory requirements via the specialist trade. Please submit or send faulty devices postage paid together with an error description to your responsible salesperson (specialist trade/installation company/elec- trical specialist trade). They will forward the devices to the Gira Service Center.
- Page 8 Gira Giersiepen GmbH & Co. KG Elektro-Installations- Systeme Postfach 1220 42461 Radevormwald Deutschland Tel +49 (0) 21 95 / 602 - 0 Fax +49 (0) 21 95 / 602 - 191 www.gira.de info@gira.de...
