7.6 Displays on the drive system

Three multicolor LEDs (DS, MS, NS) in the colors green, yellow and red are available on the
drive system for status and fault messages.
LED EtherCAT
DS Drive Status
MS RUN-LED (EtherCAT
Drive Statemachine)
NS ERR-LED (EtherCAT
Error State)
Drive Status
DS
7.6.1 LED codes DS
LED DS is the drive LED which is identical for all bus system types.
Status
LED
Off
Flash:
Green
Flash:
Red
Flash:
Yellow
Flash:
Yellow,
Green
Constant:
Green
Flash:
Red,
Green
Revision: 01
LED DS
Doc. no.: 5022-D056658
Ethernet/IP
Drive Status
Module State
Fieldbus State
Drive Status
Table 7: Displays on the drive system
Meaning
Drive amplifier has no power supply or
drive is defective
Drive amplifier is in functional state but
output stage is disabled
Drive amplifier is in fault state and output
stage is disabled
Drive amplifier is in warning state and
output stage is disabled
Drive amplifier is in warning state and
output stage is enabled
Drive amplifier is in functional state and
output stage is enabled
Drive amplifier is in Firmware Update state
Operating manual
PROFINET
Drive Status
System
Failure
Bus Failure
Drive Status
Table 8: LED codes DS
