3.3 Name plate
The name plate consists of a laser inscription on the motor housing. It depends on the version of
the drive system.
Revision: 01
A
B
C
D
E
Calendar week and year of production
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
W
Doc. no.: 5022-D056658
Operating manual
Figure 3.2: Firmware code
Designation
Product designation
Material number
Serial number
Type code
Data matrix code (DMC)
Service portal code
CE mark
Intermediate circuit voltage U
Continuous stall current I
Continuous stall torque M
Maximum current I
No-load speed n
Rated current I
Insulation class
Protection class
Ambient temperature
Customer material number
Manufacturer
MAC address
PWM frequency
Bus interface
TÜV logo
Table 2: CDSR name plate
DC
0
0
max
0
n
en-13
