Operating manual

6.4.3 X1/X2: Ethernet-based fieldbus interface

Figure
Plug type on drive system: M12, 4-pin, female, D-coded at X1 and X2
Connection
Feature
Transmission
speed

6.4.4 X1: CANopen fieldbus interface (output)

The CAN ground reference is identical to the logic ground reference.
Figure
Plug type on drive amplifier: M12, 5-pin, female, A-coded at X1
Connection
Feature
Baud rate

6.4.5 X2: CANopen fieldbus interface (input)

The CAN ground reference is identical to the logic ground reference.
Figure
Plug type on drive amplifier: M12, 5-pin, male, A-coded at X2
Connection
Feature
Baud rate
en-28
Pin no.
Signal name
1
TD+
2
RD+
3
TD-
4
RD-
Unit
Minimum
value
MBit/s
Pin no.
Signal
1
Shield
2
N.C.
3
CAN_GND
4
CAN_H
5
CAN_L
Unit
Minimum
value
kbaud
100
Pin no.
Signal
1
Shield
2
N.C.
3
CAN_GND
4
CAN_H
5
CAN_L
Unit
Minimum
value
kbaud
100
Doc. no.: 5022-D056658
®
cyber
dynamic system
Function
Transmit Data +
Receive Data +
Transmit Data -
Receive Data -
Nominal
Maximum
value
value
100
Function
Screen
CAN ground
reference
CAN High
CAN Low
Nominal
Maximum
value
value
500
1000
Function
Screen
CAN ground reference
CAN High
CAN Low
Nominal
Maximum
value
value
500
1000
Revision: 01
