Doc. no.: 5022-D056658
®
cyber
dynamic system
Designation
Product designation
Material number
Serial number
Type code
Data matrix code (DMC)
Service portal code
CE mark
Intermediate circuit voltage U
Continuous stall current I
Continuous stall torque M
Maximum current I
No-load speed n
Rated current I
Insulation class
Protection class
Ambient temperature
Customer material number
Manufacturer
MAC address
PWM frequency
Bus interface
TÜV logo
Gear ratio
Table 3: CDSG name plate
Designation
Product designation
Material number
Serial number
Type code
Data matrix code (DMC)
Service portal code
CE mark
Intermediate circuit voltage U
Continuous stall current I
Continuous stall torque M
Maximum current I
No-load speed n
Rated current I
Insulation class
Protection class
Ambient temperature
Customer material number
Manufacturer
MAC address
PWM frequency
Bus interface
TÜV logo
Ball screw pitch
Table 4: CDSL name plate
DC
0
0
max
0
n
DC
0
0
max
0
n
Revision: 01
