6.2.1 Installation space

The installation size must be sufficiently large.
A minimum distance of 25 mm on all sides of the drive system must be observed.

6.2.2 Mounting position

Any mounting position can be selected.

6.2.3 Ventilation / cooling

Sufficient convection for cooling of the drive system must be ensured at the installation
location.
To avoid overheating, closed installation sites with low volume flow are not suitable for
installation of the drive system.

6.2.4 Environmental conditions for vibration/shock

The drive system fulfills the following specifications:
Vibration according to DIN EN 60068-2-6:2008
Frequency range 10 Hz – 150 Hz
-
-
Acceleration 5 g
Shock according to DIN EN 60068-2-27:2010
-
Shock form: semi-sinusoidal
-
Acceleration 50 g
-
Shock duration: 11 ms

6.3 Requirements for power adapters and supply voltage

The drive system's logic supply and power supply (12-60 VDC) must be provided using power
adapters or supply voltage sources with safe extra low voltage in SELV/PELV design to
IEC 60950 / EN 60204. Power adapters or supply voltage sources having only basic installation
are not permissible.
en-24
Electrical work performed in damp areas may result in electric
shocks and can cause serious injuries and even death.
Carry out the electrical assembly only in dry areas.
The use of unsuitable power adapters not in SELV/PELV design
can lead to dangerously high voltages in the event of a fault, which
could lead to dangerous electric shocks resulting in injuries
or death.
Doc. no.: 5022-D056658
®
cyber
dynamic system
Revision: 01
