Operating manual

7.4 Operation

Circumferential radial forces on the shaft are not permitted.
 If this requirement cannot be fulfilled, please contact our sales department.
Always state the serial number (SN) when doing so.
 If a stop occurs as a result of the switch-off due to excessive heating, a pause between
the individual stroke cycles is recommended.

7.5 Startup software

For parameterization and startup of the drive, the startup software Motion GUI 2 is available
as well as an interactive, html-based guide.
The startup software Motion GUI 2 is used to change and save the operating parameters
of the drive system. The integrated drive system can be put into operation with the help of
software.
In the html-based help, all parameters and the function of the drive system are described.
en-34
Due to oxygen in the air, UV rays, and cable movements, the
bearing grease and the insulation materials age.

Consult our Sales department in case of excessive wear.
Due to various components and seals, a new drive can be
noticeably more difficult to move. To ensure optimum grease
distribution and running-in of the moving components, the drive
should run in as follows:

15 min at slow speed load-free (approx. 10 % vmax)

10 min at medium speed load-free (approx. 30 % vmax)

5 min with increased speed load-free (approx. 60 % vmax)
Due to the stroke movement of the piston rod, a certain amount of
lubricant leakage is possible with the CDSL version.

Nonconforming parameterization can cause uncontrolled
movements. For this reason, never change parameters whose
meaning you do not completely understand.
Doc. no.: 5022-D056658
®
cyber dynamic system
Revision: 01
