Chapter 7: Modifying the Protector Radioisotope
Configure Your Adjustable Height Ceiling Enclosure Kit Catalog Number
Use this key to configure the seven digit catalog number to order your 3-Sided Adjustable Height
Ceiling Enclosure Kit. For example, 9414501 is a 3-Sided Ceiling Enclosure Kit for a 5' x 31.7"
deep Protector Stainless Steel Radioisotope Hood with a height range of 14-19".
9 4
STEP 1.
width
number is the fifth digit of your
catalog number.
3 = 3' (XL Benchtop only)
= 4'
4
5 = 5'
= 6'
6
7 = 7' (XL Benchtop only)
= 8'
8
36
1 4
nominal
Select the
of your fume hood. This
No.
0
1
2
___ ___
STEP 2. depth
Select the
based on the model chosen.
Choose 0 for Premier and 1
for XStream. Choose 1 for
PVC. Choose 0, 1 or 2 for
the correct depth of the XL
Benchtop model. Choose 0
or 1 for the correct depth of
Stainless Steel. This is the
sixth digit of your catalog
number.
Ext. Depth Model
31.7" Premier,
XL Benchtop,
Stainless Steel
37.7" XStream,
XL Benchtop,
XL Floor-Mounted,
Stainless Steel,
PVC
43.7" XL Benchtop,
XL Floor-Mounted
Product Service 1-800-522-7658
Original instructions
___
STEP 3.
Choose the correct
height range that matches
the number. This height
range should match the
height between the top of the
hood and the building
ceiling. This is the seventh
digit of your catalog number.
No. Height Range
0 11-14"
1 14-18.6"
2 18.6-24.4"
