Chapter 2: Prerequisites
Airflows and Static Pressure
Hood Type Face
Sash at
Stainless Full open
Hoods at 28"
Perchloric
and 125
100
Radioisotope
N/A
11" OD N/A
Exhaust
Recommendations highlighted
Proper Radioisotope blower selection can be determined from these exhaust
requirements and the total system static pressure loss. Contact Labconco
Customer Service for assistance in sizing a blower system.

Filter Pack Requirements

Contact your local EPA or NRC office to determine if exhaust filtration is
required. If required, these filter packs should be located as close as possible to
the hood to expose as little of the ductwork system as possible to the
radiochemicals being filtered. Consult your Safety Officer directly for specific
filter ratings on radiochemicals being used.

Electrical Requirements

The Protector Hood models feature internal wiring for the fluorescent light
assembly and light switch. All internal wiring is terminated at the single point
wiring junction box for hook-up by a qualified electrician. The blower switch,
and light switch wires are also terminated at the single point wiring junction box
for hook-up by a qualified electrician. Refer to Chapter 3: Getting Started and
Appendix C: Protector Radioisotope Specifications for the wiring diagram for
proper electrical installation.
Les modèles Protège-capot disposent câblage interne pour l'ensemble de la
lumière fluorescente et l'interrupteur de la lumière. Tout le câblage interne est
terminé à la boîte de jonction de câbles à un seul point de raccordement par un
électricien qualifié. L'interrupteur de la soufflerie, et fils de l'interrupteur de
lumière sont également mis fin à la boîte de jonction de câbles à un seul point de
raccordement par un électricien qualifié. Reportez-vous au Chapitre 3: Mise en
route et à l'Annexe C: Protector radio-isotopes Spécifications pour le schéma de
câblage pour l'installation électrique appropriée.
8
Velocity (fpm) Airflow Volumetric Rate (CFM) @
Sash at 62.5% Static Pressure (inches of water)
open 4'
at 18" Hood
200 905, 0.39" 1195, 0.52" 1475, 0.78" 2050, 0.44"
160 725, 0.25" 955, 0.33" 1180, 0.50" 1640, 0.28"
125 565, 0.15" 745, 0.20" 920, 0.31" 1280, 0.17"
100 455, 0.10" 595, 0.13" 740, 0.20" 1025, 0.11"
Eco Energy Saving Air Foil
5' 6'
Hood Hood
Product Service 1-800-522-7658
Original instructions
8'
Hood
