Silver Control: Part No. 52347 & Green Control: Part No. 52348 - Chore-Time LIBERTY Feeding System Installation And Operator's Manual

Parts List
Silver Control: Part No. 52347 & Green Control: Part No. 52348
KEY PART NO. DESCRIPTION
1 52397
2 51631
3 4416-7
4 24683
5 51630
6 51629-3
51629-2
7 8757
8 28075
9 2529-937
2529-938
10 6776
11 24702
12 6968-1
13 25064
14 25433
15 34018
16 6723
17 40749
54
Center Support Cone
LIBERTY Feeder Pan
10-24 X .375 HXHD Screw
Support Bracket
LIBERTY Pan Support
LIBERTY Feed Cone (SILVER)
LIBERTY Feed Cone (GREEN)
Rivet 1/8 X 1.00
#10 Twin Helix Screw
Control Decal (SILVER)
Control Decal (GREEN)
Switch Box Cover
Switch Box
Gasket
Switch Box Mount
Stop Panel
10-24 Lock Nut
Flat Washer
Switch Box
LIBERTY® Feeding System with Electronic Sensor (ES)
KEY PART NO. DESCRIPTION
18 14434 End Control Body
19 41363 Deflector Panel
20 25045 Paddle Retainer
21 6972 Spring
22 46123 Paddle
23 14432 Bottom Cover
24 2527-9 Danger Decal
25 24682 Control Cover
26 5083-8 Socket Head Screw
27 44794 Drive Tube Weldment
28 4642 Drive Block
29 1907-5 Insulation Material
30 46091 Actuator Switch
31 25495 Control Cord
32 24685 1/2" Water Tight
33 46122 Switch Bracket
34 23810 90° Conduit Connector
35 26982-1 Flex Conduit
36 26980 1/2" Liquid Tight Connector
37 4188 Anchor
MF2426B
