Parts List

ACTUATOR KIT: Part No. 52494

50
KEY PART NO. DESCRIPTION
1 52494 LIBERTY ACTUATOR ASSEMBLY
2 52495 ACTUATOR
3 52586 INSULATOR & PULLEY ASS'Y
4 48933 ACTUATOR BASE
5 4404-4 1/4-20 X 2.5 HEX BOLT
6 48487 CLAMP HALF
7 9126 TUBE CLOSURE
8 3527 BAND CLAMP
9 14585 TUBE CLOSURE KIT
10 24063 1.75 TUBE CLAMP
11 24302 11" SPRING
12 1826 SMALL CLAMP
13 14898 1/8" CABLE CLAMP
LIBERTY® Feeding System with Electronic Sensor (ES)
MF2426B
