SOM RF Specification for WIFI, BT

The SOM includes the following radio interfaces from a single QCA6174A-1 module:
o ANT1: Wi-Fi antenna 1 + BT
o ANT2: Wi-Fi antenna 2
Antenna 1: The antenna 1 connector is for one of the two Wi-Fi antennas as well as the single
Bluetooth antenna.
Antenna 2: The antenna 2 connector is for the second Wi-Fi antenna.
By default, both antenna ports are connected by coaxial cables to the PCB trace antennas on the carrier
board. Note that two dual-band (2.4GHz + 5GHz) antennas are required to be connected to achieve
full performance of the Wi-Fi interface. If only Bluetooth is being used, then only a single 2.4GHz
antenna connected to antenna 1 is necessary.
The SOM WiFi/BT module is a pre-certified module for FCC and Industry Canada (see FCC ID:
2AFDI-ITCNFA324 for details). Please note that the on-board PCB antennas were not the antennas
used for the SOM WiFi/BT module certification.
For details on connecting the WiFi module to the on-board PCB antennas on the carrier board, refer to
section below.
2 x MIPI CSI
2 x USB 2.0/ 3.0 OTG
1 x MIPI DSI
2 x PCIe 1Lane Gen2
1 x Gigabit Ethernet
1 x HDMI 2.0a
3 x Memory / Storage
2 x I2C
2 x Debug UART
1 x JTAG
14
Copyright Intrinsyc Technologies Corporation
Camera Connectors MIPI Alliance
CSI1, CSI2 Specification v1.0
USB3.0 Standard
100- pin display MIPI Alliance
connector. Interfaces Specification v1.01.
with Intrinsyc Display MIPI D-PHY
Adapter Board Specification v0.65,
v0.81, v0.90, v1.01
PCI Express
Specification, Rev 2.1
RGMII interface
HDMI capable of 4K HDMI 2.0a
60Hz content
1 x 8 bit NAND JEDEC/MMC standard
1 x 4 bit QSPI version 5.0, SD 3.0
1 x 4 bit SDIO
I2C1, I2C3
1x Enhanced UART
for A53
1x Standard UART for
M4
