Interface Panel - RGBlink Mini Quick Start Manual

Interface Panel

HDMI OUT
HDMI IN
DC 12V
LAN
USB
AUDIO IN/OUT
© Xiamen RGBlink Science & Technology Co., Ltd.
Ph: +86 592 5771197 |
1 HDMI Output port, connect to display to show Preview (6
pictures) or PGM.
4 HDMI Inputs, connect to input source from HD camera or PC
1 DC Jack for power input, connect to 12V/4A power adapter.
Communication port to link dedicated software for control
USB3.0 output, capture signal via third party streaming software
and push to live broadcasting websites
AUDIO In, analog audio input port, connect to microphone
AUDIO OUT, analog audio output port, connect to loudspeaker.
