The operation process and precautions of PTZ
camera control on RGBlink mini+
Note: Please make sure your PTZ camera supports the Sony Visca protocol.
1. Connect mini+ and PTZ camera:
1.1 Connect mini+ and PTZ camera directly:
Suppose the IP address of mini+ is 192.168.1.101, and the default IP address of
the PTZ camera is 192.168.100.88.
1.1.1 Connect the mini+ to the PTZ camera with a network cable.
1.1.2 Press the M button on the mini+ and turn the right rotary knob(Y rotary
knob) to IP SETTING.
1.1.3 Modify the IP address of mini+ to 192.168.100.101 by operating the right
rotary knob(Y rotary knob).
Address：S601 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian P.R.C
Tel：4008 592 315
Email:
support@rgblink.com
Fax：+86 592 5788216
http://www.rgblink.com
1
Advertisement
Related Manuals for RGBlink mini+
Summary of Contents for RGBlink mini+
- Page 1 The operation process and precautions of PTZ camera control on RGBlink mini+ Note: Please make sure your PTZ camera supports the Sony Visca protocol. 1. Connect mini+ and PTZ camera: 1.1 Connect mini+ and PTZ camera directly: Suppose the IP address of mini+ is 192.168.1.101, and the default IP address of the PTZ camera is 192.168.100.88.
- Page 2 1.2.1 First set my computer IP to 192.168.100.100 (any one of 192.168.100.2- 192.168.100.254), the subnet mask is 255.255.255.0, and leave the others blank. Address：S601 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian P.R.C Tel：4008 592 315 Fax：+86 592 5788216 Email: support@rgblink.com http://www.rgblink.com...
- Page 3 LAN IP address of the PTZ camera to a static IP address in the same network segment as the router’s, for example, 192.168.1.88. Address：S601 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian P.R.C Tel：4008 592 315 Fax：+86 592 5788216 Email: support@rgblink.com http://www.rgblink.com...
- Page 4 1.2.5 Reset the computer's IP address to 192.168.1.100 (any one of 192.168.1.2- 192.168.1.254), the subnet mask is 255.255.255.0, and the others are blank. Address：S601 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian P.R.C Tel：4008 592 315 Fax：+86 592 5788216 Email: support@rgblink.com http://www.rgblink.com...
- Page 5 UDP port, as shown in the following figure: 2.1 Set the corresponding communication port on the PTZ camera, such as UDP port 1259. Address：S601 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian P.R.C Tel：4008 592 315 Fax：+86 592 5788216 Email: support@rgblink.com http://www.rgblink.com...
- Page 6 3. Set the corresponding camera IP on the mini+ to the IP address of the PTZ camera. Address：S601 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian P.R.C Tel：4008 592 315 Fax：+86 592 5788216 Email: support@rgblink.com http://www.rgblink.com...
- Page 7 3.3 Set the IP of the camera you want to control to the corresponding IP address. For example, set the IP address of camera 1 to 192.168.1.88. Address：S601 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian P.R.C Tel：4008 592 315 Fax：+86 592 5788216 Email: support@rgblink.com http://www.rgblink.com...
- Page 8 3.5 Switch back to the Control option, and enter the Control interface, then you can start to control your PTZ camera. Address：S601 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian P.R.C Tel：4008 592 315 Fax：+86 592 5788216 Email: support@rgblink.com http://www.rgblink.com...
- Page 9 Note: When operating the camera, mini+ needs to remain in the Control interface, otherwise the PTZ camera cannot be controlled. Address：S601 Weiye Building Torch Hi-Tech Industrial Development Zone Xiamen,Fujian P.R.C Tel：4008 592 315 Fax：+86 592 5788216 Email: support@rgblink.com http://www.rgblink.com...
