Wheeled Puck Wheel Inspection
The wheels on the wheeled pucks that are used on the MagneMover LITE transport system
must be inspected regularly to help maintain proper operation.
1. Remove the wheeled puck from the MagneMover LITE transport system (see
Pucks on page
Lateral Guide
Septum Wheels
(if supplied)
2. Inspect the wheels for high rotating friction and tread damage (see
3. If any wheels are showing excessive friction or tread damage replace the wheel set, see
Replace Wheeled Puck Wear Surfaces on page 91
Wear Surfaces on page
4. Replace the puck on the transport system (see
MagneMover LITE Service Manual
78).
Wheels
Figure 9: Puck Wheel Inspection
94.
Rockwell Automation Publication MMI-UM037A-EN-P - April 2020
Preventive Maintenance
Figure
or Replace Tandem Wheeled Puck
Replace Pucks on page
Maintenance
Replace
Suspension
Wheels
9).
78).
41
