Rockwell Automation MagneMotion MagneMover LITE Service Manual page 99

3. Hold the left puck in place and place the right puck in the fixture keeping it as far away
from the left puck as possible as shown in
near, the other puck.
First Puck
MagneMover LITE Service Manual
To avoid injury from strong magnetic attractive
forces:
• Handle only one puck at a time.
• Do not place any body parts, such as fingers,
between the puck and any ferrous material or
another magnet array.
• Pucks not being used must be secured individu-
ally in isolated packaging.
Second Puck
Figure 32: Place Second Wheeled Puck in Fixture
Rockwell Automation Publication MMI-UM037A-EN-P - April 2020
Figure 32. Do not move one puck over, or
CAUTION
Strong Magnets
Maintenance
Repair
Installation
Fixture
99
