Maintenance
Repair
8. Locate the plate assembly over the standoffs on the magnet assembly. Secure using
new M4 x 22 mm flat head screws and tighten to 1.5 N•m [13 in•lb].
The Loctite must cure for 2 hours at 22° C [72° F] before using the puck.
9. Replace the puck on the MM LITE transport system (see
84
Figure 22: Adhere Preload Spacer to Underside of Top Plate
Rockwell Automation Publication MMI-UM037A-EN-P - April 2020
Center Plate
Compliant Spacer
Glue Dot
Top Plate
Replace Pucks on page
MagneMotion
78).
