- Page 1 RC6GS Digital 6-Channel Proportional RC System Instruction Manual V1.4 Adaptable to RC Cars/Boats/Robot CE FCC RoHS * Please be kindly noted that this manual will be updated regularly and please visit RadioLink official website to download the latest version.
- Page 2 RadioLink Electronic Ltd www.radiolink.com Thank you for choosing RadioLink 2.4 GHz 6 channels radio -- RC6GS V2. To fully enjoy the benefits of this product and ensure safety, please read the manual carefully and set up the device as instructed steps.
- Page 3 Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Packing list Items RC6GS V2 Transmitter R7FG Receiver Lanyard User Manual...
-
Page 4: Table Of Contents
RadioLink Electronic Ltd www.radiolink.com CONTENTS ........................... 1 RC6GS V2 Control System .............................. 1 Transmitter ..............................2 Receiver ....................2 1.2.1 Receiver Installation and Binding ..........................3 1.2.2 Working Mode 1.2.3 Gyro Setup ............................4 ......................5 1.2.4 Signal/RSSI Real-time Return ..................... -
Page 5: Rc6Gs V2 Control System
Control System RC6GS V2 Remote RC6GS V2, transmitter with chip STM32F103RB, 12ms only from transmitter to the receiver, thus provide synchronous control and perfect performance . The same FHSS spread spectrum and 67 channels pseudo random frequency sequence hopping of AT9S makes RC6GS V2 have superior anti-interference ability both at the same frequency band and different frequency bands. -
Page 6: Receiver
Battery Tray Dimension: 89*59*18mm (3.5”*2.32”*0.71) ⚫ Model Memory: 10 1.2 Receiver R7FG(Standard Pack) RC6GS V2, sells with R7FG, 2.4GHz 7 channels receiver, gyro integrated and high voltage servo supported. Telemetry Port of Model Battery Voltage Antenna CH1 Steering CH2 Throttle... -
Page 7: Working Mode
RadioLink Electronic Ltd www.radiolink.com and release, the led will flash quickly, meaning binding process is ongoing. 4. When the led stops flashing and is always on, binding is complete and there will be a signal tower shown on top of the LCD screen of the transmitter. If not succeed, the led will keep flashing slowly to notify, repeat the above steps. -
Page 8: Gyro Setup
RadioLink Electronic Ltd www.radiolink.com R7FG Working Mode Working Mode Mode 1 Mode 2 Mode 3 Mode 4 Note Red&Blue Red&Green Indicator Color Green Blue (Purple) (Orange) Multicolor light indicator on With Gyro means gyro function on Channel Corresponding signal output in different channel... -
Page 9: Signal/Rssi Real-Time Return
Only when the main-board of RC4GS is produced after 2018-01-01 and updated with the latest version of V6.0.1 or above that can make binding with R7FG/R8F. The factory default firmware version of RC6GS V2 is V6.1.0. Besides the return of RSSI, receiver voltage, model battery voltage (maximum up to 6S lithium battery) can also be returned in real time. -
Page 10: Rc6Gs V2 Functions
RadioLink Electronic Ltd www.radiolink.com II. RC6GS V2 Functions 2.1 Display on LCD Screen Transmitter Voltage Model Name Subsidiary ID Model Voltage (Telemetry 2S-6S Transmitter battery) Name Steering Trim Throttle Trim When you power on the transmitter, LCD screen shows Model Name, Transmitter Name, Transmitter Voltage, Steering Trim, Throttle Trim, Model Voltage, Subsidiary Model ID, Returned Signal. -
Page 11: Language "Language
Numbers at the bottom means the current firmware version. Eg. V6.1.0 in above picture. 2.3 Model Select "MODEL" RC6GS V2 can store model memories for ten models. Use this function to call a new model. (1) Access the function menu (By pressing “Exit” and“Enter” buttons simultaneously and holding them down for one second), press “Enter”... -
Page 12: Steering Exponential "Stexp
RadioLink Electronic Ltd www.radiolink.com amount adjustment, and channel 3 servo up side/down side operation amount adjustment during linkage. Correct the maximum steering angle and left and right steering angles when there is a difference in the turning radius due to the characteristics, etc. of the vehicle. -
Page 13: Steering Speed "Stspd
RadioLink Electronic Ltd www.radiolink.com 0%~+100%: Sensitivity around neutral position is high, getting lower when approaching ends Steering operation curve adjustment (1) Access the function menu (By pressing “Exit” and “Enter ”buttons simultaneously and holding them down for one second ), press “Inc(+)” button three times to chose EAP function. - Page 14 RadioLink Electronic Ltd www.radiolink.com starting value. (2) Press "Enter" button ,starting value stop flashing,adjustment is completed. (3) Press "Exit" button for two times,back to the initial interface. Throttle curve adjustment Adjustment method for CRV curve Setup Items Mode: ON/OFF RATE: 0%~100% 1.
-
Page 15: Throttle Speed "Thspd
RadioLink Electronic Ltd www.radiolink.com Adjustment range RATE: -100 ~ 0 ~ +100 0~-100: flat braking 0: uniform braking 0~+100: sensitive braking Brake side adjustment (select BRK) (1) Press “Enter” key, the current BRK value will blink, use “Inc(+)” button to adjust the + side when you want to quicker the rise and use“Dec(-)”... -
Page 16: Function "A.b.s
RadioLink Electronic Ltd www.radiolink.com (4) When ending setting, return to the initial screen by pressing “Exit” button twice. Adjustment method for SPEED2 Setup items MODE: Speed type selection LOW: Low side range speed adjustment HIGH: High side range speed adjustment... - Page 17 RadioLink Electronic Ltd www.radiolink.com TGP: Operation point DTY: Cycle duty ratio STM: Steering mixing -ABP(Amount of brake return): Sets the rate at which the servo returns versus trigger operation for brake release. When set to 0, the ABS function is not Performed.
- Page 18 RadioLink Electronic Ltd www.radiolink.com (3) Pulse speed adjustment Select setting item "CYC" by pressing “Dec(-)” or “Inc(+)” button, then press “Enter” key and the initial value of “CYC” will blink. Use “Dec(-)” or “Inc(+)”button to adjust the pulse speed (cycle).
-
Page 19: Throttle Acceleration "Accel
RadioLink Electronic Ltd www.radiolink.com Steering mixing (STM) OFF, N10 ~ N100, E10 ~ E100 Initial value: OFF When steering mixing is set and steering operation enters the set range, "*" is displayed in front of the number. When mixing is OFF, the A.B.S function can operate over the entire steering range. -
Page 20: Idle-Up "Idlup
RadioLink Electronic Ltd www.radiolink.com the initial value of “BRAK” will blink, then use“Dec(-)”or“Inc(+)”button adjust the acceleration amount. (Note: In the interface of adjusting the value, return to the initial value"0%" by pressing “Dec(-)” and “Inc(+)” buttons simultaneously for about 1 second.) Press “Enter”... -
Page 21: Servo Reverse "Reverse
RadioLink Electronic Ltd www.radiolink.com TH: -100~0~+100 CH3: -100~0~+100 CH4: -100~0~+100 CH5: -100~0~+100 CH6: -100~0~+100 Initial value : 0 (1) Enter the function menu and use “Dec(-)”or “Inc(+)” button to access SUBTR function. (2) Press “Enter” button to get into SUBTR function interface. -
Page 22: Brake Side Adjustment "Atl
RadioLink Electronic Ltd www.radiolink.com Setup Item Steering D/R Throttle D/R RATE Steering D/R rate (RATE) 0%~100% Initial value: 100% Throttle D/R rate (Throttle D/R RATE) 0%~100% Initial value: 100% (1) Enter the function menu and use “Dec(-)” or “Inc(+)” button to access D/R function. - Page 23 RadioLink Electronic Ltd www.radiolink.com Programmable Mixes "PMIX" MXMD:Mix mode Enter the function menu and use“Dec(-)”or “Inc(+)” button to access PMIX function, then press “Enter” button to get into PMIX function interface. (1) Master channel Channel selection (MST) ST, TH, CH3, CH4, CH5, CH6 Initial value: ST Select setup item"MST"...
- Page 24 Same as ONE TO TWO mix control. Dual Mix Control： As controlling dual-engine vehicles drive forward/backward and turn left/right, two mix controls at the same time are needed. RADIOLINK RC6GS V2 V2 has two programmable mix controls. Reverse Setup before Mix Control Setup Before setting the mix controls, please check if the reverses working correctly by testing its wheel and throttle.
- Page 25 R7FG 1. Throttle Reverse：NOR-REV Hold RC6GS V2 V2 as the below pic. Normally, pull the throttle, the right track should be moving forward while push the throttle and the right track should be backward. Pull the throttle，right track moves forward，left track remains still If pulling the throttle and the left track moves backward;...
- Page 26 RadioLink Electronic Ltd www.radiolink.com Turn the wheel clockwise, the left track moves forward，the right track remains still If turning the wheel right and the right track moves backward; Or turning the wheel left and the right track moves forward, meaning the initial steering is reversed and needs to be set. Please refer to the “button operation”and get into below interface to complete the setup.
-
Page 27: Auxiliary Channel "Aux-Ch
RadioLink Electronic Ltd www.radiolink.com Throttle mix steering setup completed, both tracks moves forward when pulling the throttle 2. Steering mix Throttle：Tracked vehicles turning left/right As tracked vehicles turning left/right is controlled by steering, steering leads throttle in the mix control. That is, Master-Steering, Slave-Throttle. -
Page 28: Model Name "Name
Press “Enter” button, the adjusted value stops blinking, now the value has been set. 2.18 Model Name "NAME" RC6GS V2 V2 stores model memories for ten models. Each model memory can be named separately according to user’s requirement. Factory default name: MODEL1 (1) Enter the function menu and use “Dec(-)”... -
Page 29: Gyro Sensitivity "Gyro
RadioLink Electronic Ltd www.radiolink.com out, please immediately stop running when the alarm starting to ring. 2.20 Gyro Sensitivity “GYRO” This function is available to set gyro sensitivity and VR mixing ON or OFF. When MIX set OFF, gyro is disabled while when MIX set ON, you can adjust gyro sensitivity STD or VR. -
Page 30: Subsidiary Id"Id Seed
There are totally 10 independent subsidiary IDs can be stored. For example, RC6GS V2 V2 has completed the binding with 10 different boats and the setup of respective parameters. Turn on the ID SEED function, select ID.1 boat and drive it to the central of water but it stops working unexpectedly.
