Safe servicing

To avoid injuries to both the service engineer and the subsequent
Š
user of the scooter, it is important to get to know the product
before servicing it.
Be particularly aware of the following:
Š
The Mini Crosser MUST be turned off at the main switch. If
Š
electrical components are being serviced, the positive terminal on
the battery MUST also be disconnected.
If the voltage needs to be measured in the course of
Š
troubleshooting, take great care not to short-circuit anything.
Take great care not to short-circuit the battery terminals.
Š
Be careful not to lift heavy parts such as the seat, battery and
Š
motor gear incorrectly or drop them.
Make sure to raise one rear wheel off the ground so that the
Š
scooter cannot drive off accidentally.
Use professionally maintained tools.
Š
Where lock nuts are used, NEW ones MUST be fitted when the
Š
scooter is reassembled.
Take care to fit new cable strips in the same way as the old ones.
Š
Make sure that no cables can be trapped by moving parts or stick
out in such a way as to catch on things.
End every service by making sure that the product is roadworthy:
Š
- Check that all the connectors are plugged in correctly.
- Check that all the mechanical parts are properly secured.
Turn the scooter on and check
- that the magnetic brake clicks when the accelerator is activated.
- When the accelerator is released, it must not be possible to push
the scooter.
