User Menu - Medema Mini Crosser M2 Service Manual

Medema A/S
Service manual P9-0157-S

User menu

Term
Menu / information
Key switch
Speed selector
Battery indicator
Trip meter
Hand brake
Description
Press the button and a menu at the top of the display
switches between "Date", "Time", "Complete km",
"Complete running time", "Battery Voltage" Service
"and" inclination "."Slope" is optional, and appears
only if it is engaged.
Button Menu / information are also used to modify the
user parameters.
Access these parameters by holding the menu button
for approx. 3 sec.
To start the vehicle:
Turn the key to position (1). The first half second after
the Mini Crosser is on, the control is making a safety
check of the electrical system. If the accelerator is
affected during this time, the Mini Crosser will not be
able to run, before the key again has been turned at 0
and back to 1 again.
The turtle indicates lowest speed range. 0-6 km / h.
The hare indicates the highest speed range. Up to 15
km / h. Increase/decrease with + / - button.
The icons turtle/hare can be turned on/off from the
User menu.
The left side of the display shows battery level indicator.
Indicates that after approx. ½ seconds, the battery
state of charge. Provides a more accurate indication
after approx. 1 minute drive. When both red, yellow and
green box lights are the batteries fully charged. Can be
divided into 10 or 3 boxes. When the view is down the
bottom of the yellow batteries should be recharged as
soon as possible. If there is only light in the red boxes
or fl ashing the batteries must be charged immediately.
TRIP button resets the trip meter. Can be used while
driving.
Works on the left rear wheel and should only be used
as extra brake / emergency brake and parking brake.
It can be blocked in the locked position. Also available
as a foot brake.
12 of 70 Version 2.0.9 - 2018
