Medema Mini Crosser M2 Service Manual page 18

Medema A/S
Service manual P9-0157-S
Area Component
Steering column
(contd)
Cables
Gas spring
Key switch / charging
socket
Chassis / seat / Footplate
covers
Seat post
Chassis / seat / Seat
covers (contd)
Covers
Other mechanical
components
Check and remedy
(*) On models with an 8 mm bolt
going into the steering shaft from
the aluminium bottom section of
the steering column. The bolt can
work loose if the steering column
is twisted/knocked hard. This can
be remedied by drilling a hole for a
split pin between the steering shaft
and the aluminium section. Contact
Medema A/S.
Check that the cables cannot
become trapped or be subjected
to strain when the handlebars are
turned or the steering column is
folded down.
Check:
That the gas spring locks the steering
column securely.
Check that there is no play in the
release lever and the bolts/bushes
securing the gas spring.
Check that the key switch does not
wobble.
Clean with a damp cloth or
compressed air if dirty. If the contacts
are corroded, clean them with
contact spray or replace the charging
sockets.
Check the plastic rivets securing the
mat. Fit new ones if necessary.
Check that it is properly secured and
in good condition.
Check that:
The release lever locks the seat
properly.
The seat is firmly secured on the seat
frame/plate.
The seat tube is in good condition. If
necessary, lubricate the tube with a
little acid-free grease.
The armrests are in good condition.
Check that the plastic covers are in
good conditions. Parts with sharp or
projecting edges should be replaced.
The same applies to covers with an
operational function, e.g. the splash
guard and battery cover. (water in the
controller)
Cleaning: See the section on
Cleaning.
Check that the other components
work properly.
18 of 70 Version 2.0.9 - 2018
