O2 Sensor Connection - Dynojet POWER COMMANDER III Installation Instructions

i925-411 www.powercommander.com
Unplug
Unplug
15 Disconnect the stock rear O2 sensor from the
main wiring harness (Fig. K).
This connector is located near the coolant
reserve bottle, near the connection where you
plugged in the PCIII.
If you can not find this connection follow the
wires coming out of the exhaust and follow
them to the main wiring harness.
16 Plug one of the Dynojet O2 eliminators into
the stock wiring harness.
The stock O2 sensor will not be connected at
this time. The sensor can be removed from
the exhaust if desired.
17 Disconnect the stock front O2 sensor from the
main wiring harness (Fig. L).
This connector is located on the left hand,
bottom side of the engine.
If you can not find this connection follow the
wires coming out of the exhaust and follow
them to the main wiring harness.
18 Plug one of the Dynojet O2 eliminators into
the stock wiring harness.
The stock O2 sensor will not be connected at
this time. The sensor can be removed from
the exhaust if desired.
Note: The installation of the O2 eliminators
will allow you full control over your entire
fuel curve. Without the eliminators installed
you will not be able to adjust the fuel curve
under 3000rpm and under 10% throttle.
19 Reinstall the fuel tank and seat.
2005-2007 KTM Superduke - PCIII USB - 5
