Function Summary and Button Definition

◆Function Summary

KD68C has many functions to fit the users' needs. The indicating contents are
shown as follows:
●Battery level indicator
●Motor output indication
●Assistance level
●Speed indication
●Trip time
●Trip distance and total distance
●The lighting On/Off
●Error code indication
●Various Parameters Settings (e.g. wheel diameter, speed limit, battery level bar,
controller current limit, password enable, etc.)
●Recover Default Settings

◆Button Definition

There are three buttons (
functions respectively: ON/OFF, UP, DOWN.
Installation:
KD68C can be mounted on the left side of handlebar close to its grip. Adjust the
angle for a good display view. Cut off the power before connecting the corresponding
connectors between display and controller..
indication
, ,
2
) on the KD68C display that represent
Assistance-evel
