Smart Connect Multi-loop Installation Manual
EXPLANATION OF ACCESS LEVELS
The Smart Connect System has the following access levels.
ACCESS
ACCESSED BY
LEVEL
1 General public
2a Responsible person
2b Responsible person
3a Installer / Engineer
3b Installer / Engineer
4 Authorised Service Engineer
Care should be taken to ensure that the access method for each level is only available to suitably qualified personnel.

Additional Features

There is PC configuration software, a mobile monitoring application, a repeater panel and a LED Expander PCB available.
PC Configuration Software: Smart Configurator
Repeater Panel: SMART/REP
www.zetaalarmsystems.com
ACCESS METHOD FUNCTIONS ACCESSED
View Panel
Default state
Override delay (if used)
Start sounders
stop sounders
Enter user access code
Silence buzzer
(default 0001)
Reset panel
Access User Menu
Enable / disable sections of system
Enter user access code Test Mode
(default 0001), and press View Zones / Points
Menu Access Icon View event log
Turn off delay
Configure loops
Assign zones
Assign Text to each point
Enter Engineer Password
Modify Alarm Operation Programming
(Default 9999), and press
Configure network (if fitted)
Menu Access Icon
System Diagnostics (LED blink / loop Autocheck)
Change passwords
Configure TCP/IP Port
Connect wiring during Install
Open Enclosure Battery check during Maintenance
Update Cause & Effect programming via USB
Open Enclosure & PC S/W Update Panel Firmware, Add new language
