Smart Connect Multi-loop Installation Manual
Power on Procedure
1.
After the above has been completed, turn the panel on (Via AC Only). The panel will follow the same power up sequence
described in initial power up section above
2.
The panel will now display one of the following messages
Message
www.zetaalarmsystems.com
Meaning
The Panel has not detected any modules fitted during its
power up check.
Power down the panel and check that the expected
modules are fitted, and that all module cables are
correctly inserted.
Note that the panel will need at least one module fitted
to run.
The panel has detected a new module added to a port
that was previously empty.
This is the usual message seen the first time a panel is
configured
The panel has detected a different type of module fitted
to a port that was previously occupied.
The panel has detected a module fitted to a port that is
the same type, but it`s serial number has changed.
This could happen if a loop module was swapped with
another one, for example.
The panel has detected no module fitted to a port that
was previously occupied.
21
