Smart Connect Multi-loop Installation Manual
Status LED's
The status of the device is shown via visual feedback. The status LED identifies the hardware status of the printer. The table below
shows the various LED signals and their corresponding status.
Status LED
OFF
ON
ON Flash x 2
ON Flash x 3
ON Flash x 4
ON Flash x 5
ON Flash x 6
ON Flash x 7
Printer Maintenance
The regular cleaning of the panel printer will help maintain its print quality and extend its lifetime. The table below shows the
recommended maintenance timeline and cleaning operations.
Every Paper Change
Printer Head
Rollers
Every 5 Paper Changes
Paper Path
Sensors
Every 6 Months or as Needed
Printer Case
Note: If the SMART Connect Multi-loop panel is installed in a dusty environment, the
times between the cleaning operations should be reduced.
www.zetaalarmsystems.com
LED Colour
Description
Green
Printer is off
Green
Printer is on: No error
Green
Printer head over temperature
Green
Printer paper empty
Green
Power supply voltage is incorrect
Green
Reception errors (Parity, frame error, overrun error)
Green
Command is not recognised
Green
Command reception has timed out
Use Isopropyl Alcohol
Use Isopropyl Alcohol
Use Compressed Air
Use Compressed Air
Use Compressed Air or a Soft Cloth
40
