Smart Connect Multi-loop Installation Manual
Panel
Charger Boost
Voltage
SMART6
29.5V DC
SMART10
29.5V DC
SMART26
29.5V DC
Securing the batteries
The SMART Connect Multi-loop has been designed so that the batteries are secured in the panel with Velcro strips.
www.zetaalarmsystems.com
Charger Float
PSU Cage Size
Voltage
27.6V DC
400W
27.6V DC
400W
27.6V DC
400W
Max Charger Current
Max Battery Size
1.1A
2 x 12V, 14 Ah
2.2A
2 x 12V, 38 Ah
2.2A
2 x 12V, 38 Ah
Fuse
Installed
5A
8A
15A
16
