Smart Connect Multi-loop Installation Manual
FUNCTIONS REQUIRED BY EUROPEAN STANDARD EN54-2
The Smart Connect Multi-loop fire alarm control panel provides the following mandatory and optional functions as prescribed by the
European standard EN54-2.
(a) Mandatory Functions
The mandatory functions and corresponding indications provided by this panel are:
•
Fire alarm condition
•
Fault warning condition
•
Disablement condition
•
Quiescent condition (when the CIE is powered by a power supply conforming to EN 54-4 and no other functional
condition is indicated)
(b) Optional Functions (Options with Requirements)
The options with requirements provided by this panel are:
•
Clause 7.8 – Output to fire alarm device(s)
•
Clause 7.11 – Delays to outputs
•
Clause 7.12.2 – Dependencies on more than one alarm signal - Type B
•
Clause 7.12.3 – Dependencies on more than one alarm signal - Type C
•
Clause 8.3 – Fault signals from points
•
Clause 9.5 – Disablement of each address points
•
Clause 10 –Test Condition
(c) Other Functions outside EN54
•
USB port (For PC configuration and software upgrading)
•
RS485 Network / Repeater connection
•
TCP/IP (Ethernet) connection (Remote access)
•
Programmable Cause / Effect on Outputs (Phased Evacuation)
•
Printer Option
•
Auxiliary Power Supply Output (via SCM-ACM)
•
Auxiliary Relay Outputs
FUNCTIONS REQUIRED BY EUROPEAN STANDARD EN54-4
The Smart Connect Multi-loop fire alarm control panel provides the following mandatory functions as prescribed by the European
standard EN54-4.
(a) Mandatory Functions
The mandatory functions and corresponding indications provided by this panel are:
•
Clause 5.1 – Power supply from the main power source
•
Clause 5.2 – Power supply from the standby power source (battery)
•
Clause 5.3 – Charger
•
Clause 5.4 – Faults
Appendix B: STANDBY BATTERY REQUIREMENTS
A spreadsheet is available for calculating the standby battery requirements. The table below is provided for information:
Model Number
Description
SMART6
Smart Connect Multi-loop 6 expansion port FACP
SMART10
Smart Connect Multi-loop 10 expansion port FACP
SMART26
Smart Connect Multi-loop 26 expansion port FACP
SCM-LCM
Loop Card Module
www.zetaalarmsystems.com
Standby Current (mA)
Alarm Current (mA)
(Mains Fail Condition)
110
112
120
87*
87*
42
