Smart Connect Multi-loop Installation Manual
Control Panel Installation and Dimensions
Enclosure Dimensions
See table 1 for full dimensions see table 1.
Table 1
Panel
A
B
SMART/6
535mm
385mm
SMART/10
665mm
535mm
SMART/26
665mm
975mm
Panel Construction Details
All components are manufactured from Zintec.
Large and Medium Smart Multi-loop Enclosures
Back box and door 1.5 mm
Door plate 0.9 mm
All internal parts are 0.9 mm
Small Smart Multi-loop Enclosure
All parts are 0.9 mm
Smart Repeater Enclosure
All parts 0.9 mm.
The paint colour for the main box and door is RAL9005 Black Leatherette (Black version).
The internals are RAL9005 Black Leatherette.
www.zetaalarmsystems.com
C
D
E
355mm
150mm
120mm
505mm
200mm
170mm
945mm
200mm
170mm
F
Top
Side
Knock
Knock
outs
outs
505mm
18
12
635mm
26
8
635mm
64
28
Bottom
Max
Knock
Battery
outs
Size
4
2 x 14Ah
4
2 x 38Ah
20
2 x 38Ah
10
