Explorer Mini
4.1.3

Installing the seat

The center of gravity is affected when the seat is installed.
The table and backrest unit must be in the highest position before
you can install the seat. Otherwise there will not be enough space to
install the seat.
1. Put the table and backrest unit in its highest position. For
instructions on how to adjust the height of the table and backrest
unit, see 4.2.1 Adjusting the height of the table and backrest unit .
2. Remove the tightening knob from the column.
68
Figure 32. Remove the tightening knob from the column.
Adjustments
