Explorer Mini
8.2

Electromagnetic immunity

Guidance and manufacturer´s declaration
The Explorer Mini and the battery charger (PF2401A5SL) are intended for use in the electromagnetic environment specified
below. The customer or the user of the Explorer Mini and the battery charger (PF2401A5SL) should assure that they are used in
such an environment
Explorer Mini
Immunity test
Electrostatic discharge
(ESD)IEC 61000-4-2
Power frequency
(50/60 Hz) magnetic
field IEC 61000-4-8
Battery charger (PF2401A5SL)
Immunity test
Electrostatic discharge
(ESD) IEC 61000-4-2
134
Test level IEC 60601 Compliance level
±2 kV, ±4 kV, ±6 kV ±2 kV, ±4 kV, ±6 kV
contact contact
±2 kV, ±4 kV, ±8 kV ±2 kV, ±4 kV, ±8 kV
air air
30 A/m 30 A/m
Test level IEC 60601 Compliance level
±2 kV, ±4 kV, ±6 kV,
±2 kV, ±4 kV, ±6 kV
±8 kV contact
contact
±2 kV, ±4 kV, ±8 kV,
±2 kV, ±4 kV, ±8 kV
±15 kV air
air
Electromagnetic compatibility
Electromagnetic environment guidance
Floors should be wood, concrete or ceramic tile. If
floors are covered with synthetic material, the
relative humidity should be at least 30%.
If image distortion occurs, it may be necessary to
position the Explorer Mini further from sources of
power frequency magnetic fields or to install
magnetic shielding. The power frequency
magnetic field should be measured in the intended
installation location to assure that it is sufficiently
low.
Electromagnetic environment guidance
Floors should be wood, concrete or ceramic tile. If
floors are covered with synthetic material, the
relative humidity should be at least 30%.
