Permobil Explorer Mini User Manual page 135

Explorer Mini
Electrical fast transient/
burst IEC 61000-4-4
Surge IEC 61000-4-5
Voltage dips, short
interruptions and
voltage variations on
power supply input
lines IEC 61000-4-11
Power frequency (50/
60 Hz) magnetic field
IEC 61000-4-8
Note: U is the a.c. mains voltage prior to application of the test level.
T
±2 kV for power ±2 kV for power
supply lines supply lines
±1 kV for input/output ±1 kV for input/output
lines lines
±1 kV line(s) for power ±1 kV differential
supply line(s) mode
±2 kV for line(s) to ±2 kV common mode
earth
<5% U (>95% dip in <5% UT (>95% dip in
T
U ) for 0.5 cycle UT) for 0.5 cycle
T
40% U (60% dip in 40% UT (60% dip in
T
U ) for 5 cycles UT) for 5 cycles
T
70% U
(30% dip in 70% UT (30% dip in
T
U ) for 25 cycles UT) for 25 cycles
T
<5% U (>95% dip in <5% UT (>95% dip in
T
U ) for 5 s UT) for 5 s
T
30 A/m 30 A/m
Electromagnetic compatibility
Mains power quality should be that of a typical
commercial or hospital environment.
Mains power quality should be that of a typical
commercial or hospital environment.
Mains power quality should be that of a typical
commercial or hospital environment. If the user of
the battery charger (PF2401A5SL) requires
continued operation during power mains
interruptions, it is recommended that the battery
charger (PF2401A5SL) be powered from an
uninterruptible power supply or a battery.
If image distortion occurs, it may be necessary to
position the battery charger (PF2401A5SL) further
from sources of power frequency magnetic fields
or to install magnetic shielding. The power
frequency magnetic field should be measured in
the intended installation location to assure that it is
sufficiently low.
