Explorer Mini
5.12.1

Charging the batteries

The Explorer Mini must only be charged with the supplied battery
charger in a dry room with good ventilation. There is a green LED
on he battery charger that is lit when the battery is fully charged.
Read the user manual supplied with the battery charger.
While the Explorer Mini charges, it is automatically locked and
cannot be driven. The LEDs on the battery indicator show the
battery status. For information on the battery status, see
3.4.6 Battery indicator .
If an error occurs when you charge the Explorer Mini, use the
trouble shooting guide for remedies. See 7.1 Troubleshooting guide .
CAUTION!
Sharp edges on cable
Be careful when connecting the cable to the socket. The edges of the three-
pin contact are sharp.
108
Handling and driving
Figure 61. Position of the charging socket.
