Hinging The Rudder - Seagull Models GISPY MOTH Assembly Manual

HINGING THE RUDDER.

Glue the rudder hinges in place using the
same techniques used to hinge the ailerons.
Hinge.
INSTALL THE AILERONS CONTROL
HORN.
1) Locate the hardware necessary to install
the control horns for the ailerons.
Fiberglass control horn
2)Position the Control horn on the Aileron
and use 30-minute Epoxy
Epoxy.
Aileron control horn.
www.seagullmodels.com
same method as same as the aileron control
horns.
Position the Control horn on the Aileron and
use 30-minute Epoxy
.
INSTALL ELEVATOR CONTROL HORN.
Install the elevator control horn using the
Fiberglass control horn
Epoxy.
Elevator control horn.
INSTALL RUDDER CONTROL HORN.
Repeat steps to install the rudder control horn
as same as steps done for ailerons.
Fiberglass control horn
.
.
5
