Seagull Models GISPY MOTH Assembly Manual page 18

GISPY MOTH.
INSTALLING VERITICAL FIN.
1) Using a modeling knife, remove the
covering from over the precut hinge slot cut
into the lower rear portion of the fuselage.
Remove covering.
2) While holding the vertical stabilizer
firmly in place, use a pen and draw a line on
each side of the vertical stabilizer where it
meets the top of the fuselage.
18
Fill epoxy.
Fill epoxy.
Instruction Manual.
3) Slide the vertical stabilizer back in
place. Using a triangle, check to ensure that
the vertical stabilizer is aligned 90º to the hori-
zontal stabilizer.
Horizontal 90º
Stabilizer.
Epoxy.
Epoxy.
Fill epoxy.
Vertical
Stabilizer.
Hinge.
