MODEL NOMENCLATURE

Model Nomenclature
As noted in the previous section, units may have more than one Serial Plate. If the unit has the gas heat option, the furnace will
have its own model number separate from the main unit.
• Table 63.1 shows the nomenclature for the gas heat section option.
• Tables 64.1 and 66.1 on the following pages show the nomenclature for the main unit.
Table 63.1 - Model Nomenclature - Gas Furnace Option for Model MPR
Digits Indicates
1,2,3 Furnace Model Prefix
4,5,6,7 Furnace Input Rating
8 Heat Exchanger
9 Ignition System
10 Gas Type
11 Modulating Capacity Control
12 Air Temperature Rise
13 Not Used
14 Furnace Supply Voltage
Description
Single, Standard Efficiency
Single, High Efficiency Condensing
Dual, Standard Efficiency
Dual, High Efficiency Condensing
Dual, Standard Efficiency
Quad, Standard Efficiency
Quad, High Efficiency Hybrid
Dual, High Efficiency Condensing
0150 = 150,000 Btu/hr
thru
1600 = 1,600,000 Btu/hr
409 Stainless Steel Heat Exchanger
Direct Spark Ignition
Natural Gas
Propane (LP) Gas
Gas Only, Multiple
Gas & Power Exhaust, Single
Gas and Power Exh Primary, Staged Secondary(s)
High Air Temperature Rise
Low Air Temperature Rise
Not Applicable
Not Currently Used
115V/1ph (transformer from main supply voltage)
MCP15-500.9
Cabinet
Value B C D
FSP
●
FSC
FMP
●
FMC
FDP
FQP
●
FQH
FDC
See Unit
See Next
Nomenclature on
Column
page 65
S ● ● ●
S ● ● ●
N
● ● ●
P
4 ●
6 ●
8 ● ●
H
L ● ● ●
N
0 ● ● ●
A ● ● ●
