DIMENSIONS - D-CABINET SIZE UNIT (WITH ENERGY RECOVERY)
Figure 48.1 - Unit Dimensions (inches)
126.81
ACCESSORY
EXHAUST HOOD
(FIELD INSTALLED)
97.39
42.37
HIGH VOLT CONTROLS
COMPARTMENT
ACCESS DOOR
25.28
EXHAUST
HOOD
EXHAUST BLWR
SERVICE DOOR
INLET END VIEW
48
CONDENSING SECTION FAN QUANTITY:
(4) FANS FOR 30 AND 40 TON UNIT
(6) / (8) FANS FOR 52 AND 60 TON UNITS
101.53
CONDENSING
SECTION
100.50
COMPRESSOR
COMPARTMENT
ACCESS DOOR
100.75
(BASE)
104.25
(LUGS)
180.73
CONDENSER
SECTION
SUPPLY AIR FILTER & DAMPERS
BLOWER DOOR
ACCESS DOOR
GAS/ELECTRIC
HEAT (OPTION) GAS SERVICE
COMPARTMENT ENTRANCE
EVAPORATOR &
ACCESS DOORS
HOT GAS REHEAT COIL
SERVICE ACCESS PANEL
137.16
FA FILTER & FA DAMPER
ERM WHEEL & RA FILTER DOOR
ERM DOOR ASSY
HOT GAS REHEAT COIL
SERVICE ACCESS PANEL
(6) 1.00" LIFTING LUGS
(4 - EACH CORNER OF UNIT)
(2 - IN BETWEEN UNIT & ERM SECTION)
15.50 111.74
(LUGS) (LUGS)
MCP15-500.9
ACCESSORY RAINHOOD
AND BIRDSCREEN
(FIELD INSTALLED ACCESSORY)
306.10
123.36
ERM
SECTION
1-1/2" NPT EVAP
COIL DRAIN
PAN PIPE
CONNECTION
BY-PASS DAMPER
REMOVABLE PANEL ASSY
ERM CONTROL PANEL ASSY DOOR
263.68
(BASE)
EVAPORATOR &
LOW VOLT CONTROLS
COMPARTMENT
ACCESS DOOR
GAS SERVICE
(8) TIE DOWN POINTS ENTRANCE
(4 - EACH CORNER OF UNIT)
(4 - IN BETWEEN UNIT & ERM)
120.94
(LUGS)
103.07
FA FILTER & FA DAMPER
ERM DOOR ASSY
99.61
57.19
40.58
APPROXIMATE AREA
FOR SIDE ELECTRIC
SERVICE ENTRANCE
(refer to Warning label
on unit for exact location)
